Specifications
1.The 8 ton disc braked air suspension rear drive bus axle is customizalbe2.Small noise and smooth brake
3.Established 1986
8 ton disc braked air suspension rear drive bus axle for 4x2 bus
| 390-4*2 Bus axle | |
| Main technical parameters | |
| Specifications | 390-4*2 Bus axle |
| Payload (KG) | 8000 |
| Maximum output torque (N.m) | 27000 |
| Self-weight (KG) | 467 |
| Track (mm) | 1800 |
| Spring pin distance (mm) | 1030 |
| Selected ratio | 4.11;4.875;5.14;5.43;5.857;6.33 |
| Diameter of hub bolt distributed cicular (mm) | Φ275 |
| Brake specification-diameter(mm)*width(mm) | Φ400*185 |
| Suitable rim | 7.00-20 |
| Suitable tire | 9.00-20 |
| Minimum clearance to ground (mm) | 265 |
| 390-4*2 bus axle hai the advantages of small noise and smooth brake ,and being optional with ABS, brake gap automatic adjusting arm,disc brake and air suspension. | |
Advantages:
- The 8 ton disc braked air suspension rear drive bus axle for 4x2 bus is customizalbe
- Established on 1986 year
- Professional technical team
- Advanced equipments
|
3.5ton/4.5ton/5.5ton/6.5ton/ 7.5ton dis braked front axle assembly |
9 Ton front drum braked axle assembly
|
13 t dingle reduction driving axle for high power heavy duty truck
|
|
16t Single reduction driving axle ; China largest torque output: 60000 |
13 ton Single reduction tandem driving axle; Press welding housing and cast steel is optional
|
13ton or 16ton double reduction tandem driving axle 13 ton axle is press welding housing;16 ton is cast steel housing |
|
The bus axle has small noise and smooth brake , be used on 9-11m long bus |
32 ton suspension for heavy duty truck, engineering heavy truck
|
26 ton rear suspension assy for heavy duty engineering vehicle |
a
For more truck axle , please visit : https://img13.fr-trading.com/productgrouplist-222106055/Truck_Axle.html
Warranty
Shanghai YIWO will provide our clients a Claim Documents before cooperate.During the warranty period,
in case of material or workmanship has occurred with spare sparts in normal operation, the defective part
will be repaired or replaced free of charge, and the parts will be delivered with next batch goods.
Spare Parts
Shanghai YIWO will provide our clients a documents on axle parts before produce. And provide a
part price list for purchase.
Installation and Maintenance
Shanghai YIWO will provide Clients the instruction manual on installation and Maintenance.
If necessary, we will send technicist to site guidance.
Technical Service
We have strong after-sale technical service team to help you solve all problem during you use our products.
