Specifications
industrial steel rollersStandard:DIN,ISO,CEMA
Dia:60-219mm
Length150-3000mm
Belt width:300-2800mm
Stainless Steel Belt Conveyor Idler
Standard:DIN15207 DIN22107 ISO1537 GB10595 CEMA
Diameter:60-219mm
Length:150mm-3000mm
belt width:300mm-2800mm
Our company can provide:
Carrying idler, return idler, impact idler, centring idler, spiral idler, comb sharp clean idler, taper shaped idler, steel idler and so on.
Selecting a idler, Confirming some parameters:
Idler dia, Idler shaft dia, Idler tube thk, Idler length, Idler material.
Standard: DIN15207, DIN22107, ISO1537, GB10595
Type conveyor DTII, TD75
Bearing NO: 6204/6205//6306/6307/6308 etc
Material: carbon steel, Rubber , nylon etc.
Belt width from 300mm to 2000mm
Bearing brand: SKF,HRB,FAG,NSK
The international Market: Europe, North America, Middle east, South America, Africa, Southeast Asia. Etc.
Advantage:
(1)Low friction coefficient, waterproof, effective sealing system,
(2). High accurate steel pipes ensure the rollers with low vibration and noise.
(3) Multi-labyrinth seals achieve waterproof and dust proof.
(4). Adopt good bearing make sure the long lifetime, stable running and good quality.
(5). Stable running, good quality and attractive price.
4.The specification range that we can provide:
Diameter: 50 to 219mm
Length: 190 to 3,500mm
Idler Dia mm |
50 |
63.5 |
76 |
89 |
102 |
108 |
114 |
127 |
133 |
139.8 |
152.4 |
159 |
165.2 |
177.8 |
190.7 |
194 |
219 |
length |
190mm-3500mm |
||||||||||||||||
Application: conveyor idlers are very important rollers fixed at the feeder piont. To protect the conveyor belt from being damaged by falling material.we not only prosime a one year quality wanrranty, but also promise to replace the failed products free in case the failed rate over 5% percent in the second year. Strictly controlled TIR, smoothly rotated, low noise, excelent dust-proof and water proof seal system, precision bearing house, bearing of choice, precision cold-drawn shaft. All above make GH rollers as your reliable choice. We never encourage client find cheaper product, we only recommend the product that suit you. We would choose different bearing for underground conveyor and overland conveyor. We would use different greast for hot wet invirment and cold dry invirment
