XCMG Made Wheel Tyre Asphalt Paver LTD650 Diesel Engine Model for Exporting

Specifications

Technical Parameters

·Main engine: 7850KG

·Overall dimension (running status): L×W×H:5300mm×2834mm×2490mm

·Hopper capacity: 5m³

·Paving width: 2800mm-4500mm

·Paving thickness: 120mm

·Max. Traveling speed: 16.7km/h

·Paving speed:  First gear: 2.82m/min.

                           Second gear: 5.84m/min.

                           Third gear: 10.46m/min.

·Crown adjusting range: ±2.5%

·Min. turning radius: 7m

·Min. road clearance: 80mm

·Max. Throughput: 100t/h

·Max. Climbing ability: 15%

·Engine:

                Model: NANCHAI X4105BG diesel motor

                Type: 4 stroke, vertical water-cooling

                Rated power: 35kw

                Rated rotary speed: 1500r/min

·Front wheel:

                Type: solid rubber tyre

                Size: 500mm×250mm(diameter ×width

               Wheel track: 2166mm

·Rear wheel:

                Type: pneumatic tire

                Specification: 11.00-20 (18 layers)

                Air pressure: 0.33-0.35Mpa

                Wheel track: 2260mm

                Wheelbase: 2640mm

·Slat conveyer: Rows: twin row

                      Conveyer width: 535mm(single row width)

                      Conveyer Speed (m/min): First gear: 10.05m/min.

                      Second gear: 20.85m/min.

                      Third gear: 37.27m/min.

·Auger:         Diameter×pitch:  300mm×290mm

                       Auger: 2387mm-3862mm

                       Auger rotary speed: First gear: 36.8 r/min.

                       Second gear: 76.1 r/min.

                       Third gear: 146.02 r/min.

·Hydraulic pump 1:

                      Model: YYB-XXXX/XX-XX

                      Type: double vane pump

                      Quantity: 1

                      Nominal pressure: 7Mpa

                      Nominal speed: 800-1800 r/min

                      Nominal displacement: 16/6ml/r

                      Purpose: steering system/ auto leveling system (selective)

·Hydraulic pump 2:

      Model: PFED-4 XXXXXX/XX-XX

                      Type: double vane pump

                      Quantity: 1

                      Nominal pressure: 21Mpa

                      Nominal speed: 800-2800 r/min

                      Nominal displacement: 56/16ml/r

       ·Purpose: vibrator motor/ working system
