RS 232 Module TPMS

RS 232 Module TPMS thumbnail-1
RS 232 Module TPMS photo-1
Negotiable MOQ: 10 Sets (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Type:
Gps Navigator
Use:
Hand Held
Screen Size:
6.5 inch
Contact Supplier Request Quote Chat Now
Josn Electronic Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
TAIWAN
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Type Gps Navigator
Use Hand Held
Screen Size 6.5 inch
Function Touch Screen, Bluetooth-enabled, Mp3/Mp4, DVD/VCD, Photo Viewer, Radio Tuner, Other, Touch Screen, Bluetooth-enabled, Mp3/Mp4, DVD/VCD, Photo Viewer, Radio Tuner, TPMS
Place of Origin Taiwan, China
Brand Name TYREDOG
Model Number TD 5030AX

Specifications

Tire Pressure Monitor System
1.Navigation with external type tire sensor
2.Easy to read out display
3.Protect your tire



1.TD 5030 AX TPMS package information

  • RS 232 module kit
  • sensor kit

2. TD5030 TPMS technical specification:

Transmitter:

  • Frequency:315 MHz
  • Pressure range:0-180 PSI
  • Accuracy:Pressure ±3 PSI,temperature±2°C
  • Operation temperature:- 40°C~125°C

Monitor specification:

  • Frequency:315MHz/433.92 MHz/2.4GHz
  • Operation temperature:-20°C~80°C

3. Product features:

RS 232 module TPMSDIY installation

Simply screw the sensors onto the valve stems in the place of valve stem caps.

RS 232 module TPMSLight and compact

Extremely lightweight and compact with specially designed electronic sensors.



RS 232 module TPMSAccurate tyre pressure sensors

Electronic tyre pressure sensors are accurate to +/- 1 PSI.



RS 232 module TPMS Abnormal pressure warming

The LCD monitor will send an immediate warning if any tyre is monitored and exceeds the pressure parameters that you chose to set.

RS 232 module TPMSAnti theft sensor mounting design

Each of the tyre pressure sensors is provided with a specially designed locknut. This secures it tightly onto the valva stem and prevents easy removal.

RS 232 module TPMSTransmission status display

The sensors will automatically transmit pressure/temperature date to the LCD monitor when it is turned on.



RS 232 module TPMSBattery power status display

The LCD monitor will display a low battery warming when either the monitor unit or any of the tyre sensors has low bettery power.

RS 232 module TPMS LCD monitor

The LCD monitor displays the 4 tyres pressures.This monitor can be mounted inside the vehicle by using either the suction cup mount or alternatively the self adhesive plate. This monitor can also be powered from the vehicle cigar lighter socket by using the power adapter supplied.



Multinational patents

This product has been patented in the US,EU ,Taiwan, China etc.The patents cover PC board circuit and mechanical design. It is illegal to copy this product in any without authorization.


4. Other Series



RS 232 module TPMS

5.Certificates

RS 232 module TPMS




6.Welcome to visit my website:.tw/index.asp


RS 232 module TPMSDIY installation

Simply screw the sensors onto the valve stems in the place of valve stem caps.

Transmission status display

The sensors will automatically transmit pressure/temperature date to the LCD monitor when it is turned on.
