Specifications
180HP,With shanghai kate diesel engine or cummins engine,ZF6WG180 Gearbox,electrical control,front dozer,rear ripper.GOST,CE.
G8180C Motor Grader
USD62,800USD PER UNIT FOB CHINA PORT.
Warranty:1800 working hours or 18monthes which come first.
Packing:one unit into one 40HQ container.
Model | G8180C | |||
Basic Specification | Engine Model | Shanghai SD diesel engine. | ||
Rated Power/Speed | kw/rpm | 138/2200 140/2300 | ||
Dimension | mm | 8900x2625x3470 | ||
Operating Weight | kg | 15400 | ||
Performance Specification | Travelling Speed, Forward | km/h | 5,8,11,19,23,38 | |
Travelling Speed, Reverse | km/h | 5,11,23 | ||
Tractive Force | KN | 79 | ||
Max. Grade ability | % | 20 | ||
pressure | Kpa | 260 | ||
Working Hydraulic Pressure | Mpa | 18 | ||
Transmission Pressure | Mpa | 1.3~1.8 | ||
Operating Specification | Max. Steering Angle for Front Wheels | ° | ±50 | |
Max. Lean Angel of Front Wheels | ° | ±17 | ||
Max. Oscillation Angel of Front Axles | ° | ±15 | ||
Max. Oscillation Angle of Balance Box | ° | front and rear 5 | ||
Frame Articulation Angle | ° | ±27 | ||
Min. Turning Radius | m | 7.3 | ||
Blade | Max. Lift Height | mm | 450 | |
Max. Cutting Depth | mm | 500 | ||
Max. Blade Position Angle | ° | 90 | ||
Blade Cutting Angle | ° | 28-70 | ||
Circle Reversing Rotation | ° | 360 | ||
Moldboard Width*Height | mm | 3965x610 | ||
FRONT DOZER:+3000USD. REAR RIPPER:+3000USD.
