Home > Products > Motor Grader > GR180 XCMG 180HP motor grader with Shanghai diesel engine ZF transmission hot for exporting

GR180 XCMG 180HP motor grader with Shanghai diesel engine ZF transmission hot for exporting

FOB Price

USD $58,800 - $78,800 / Unit

1 Unit(Min.Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Condition	New	Forward Speed(km/h)	38
Reverse Speed(km/h)	25	Place of Origin	Shandong, China
Brand Name	SDLG-VOLVO	Model Number	G8180C
Weight	15800KGS	Dimension(LWH)	8815X2640X3450
Certification	CE GOST	After-sales Service Provided	Overseas service center available

180HP,With shanghai kate diesel engine or cummins engine,ZF6WG180 Gearbox,electrical control,front dozer,rear ripper.GOST,CE.

G8180C Motor Grader

USD62,800USD PER UNIT FOB CHINA PORT.

Warranty:1800 working hours or 18monthes which come first.

Packing:one unit into one 40HQ container.

Model				G8180C
Basic Specification	Engine Model			Shanghai SD diesel engine.
	Rated Power/Speed		kw/rpm	138/2200 140/2300
	Dimension		mm	8900x2625x3470
	Operating Weight		kg	15400
Performance Specification	Travelling Speed, Forward		km/h	5,8,11,19,23,38
	Travelling Speed, Reverse		km/h	5,11,23
	Tractive Force		KN	79
	Max. Grade ability		%	20
	pressure		Kpa	260
	Working Hydraulic Pressure		Mpa	18
	Transmission Pressure		Mpa	1.3~1.8
Operating Specification	Max. Steering Angle for Front Wheels		°	±50
	Max. Lean Angel of Front Wheels		°	±17
	Max. Oscillation Angel of Front Axles		°	±15
	Max. Oscillation Angle of Balance Box		°	front and rear 5
	Frame Articulation Angle		°	±27
	Min. Turning Radius		m	7.3
	Blade	Max. Lift Height	mm	450
		Max. Cutting Depth	mm	500
		Max. Blade Position Angle	°	90
		Blade Cutting Angle	°	28-70
		Circle Reversing Rotation	°	360
		Moldboard Width*Height	mm	3965x610

FRONT DOZER:+3000USD. REAR RIPPER:+3000USD.

Shandong Zot Machinery Co., Ltd.: Contact nameIvy Zhang
Chat Now; Phone86-531-55701737; AddressFloor 11, No. 786, Xinluo Road, High-Tech Area
