45 Ton Excavator JCM With Cummins Engine

Negotiable MOQ: 1 Unit (Price negotiable depending on order volume and customization)

Key Specifications

Place of Origin:

Shandong, China

Brand Name:

JCM

Model Number:

210

Shandong Zot Machinery Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

China port

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Shandong, China

Brand Name JCM

Model Number 210

Condition New

Moving Type Crawler Excavator

Operating Weight 10000

Bucket capacity 1m3

Maximum Digging Height 10

Maximum Digging Depth 15

Machine Weight 21000

Max Digging Radius 20

Rated Speed 20

After-sales Service Provided Overseas service center available

Specifications

China excavator with cummins engine
Convenient control
Low noise
Reasonable price

China excavator with cummins engine

1. Imported diesel Isuzu(BB-6BG1TRP-01) engines and hydraulic components,

2. Bucket capacity 0.91m3,
3. The high Rated power: 103kw,
4. The operating weight: 21500 KGS

5.Dimension(L*W*H):9520*2990*2985mm

Bucket capacity		m3	0.91
Standard bucket width		mm	1,186
Operation weight		kg	21,500
Dimension (in transportation)	Overall length	mm	9,525
	Overall width	mm	2,990
	Overall height	mm	3,050
	Min. clearance	mm	485
Engine	Model		BB-6BG1TRP-01
	Total displacement	L	6.494
	Rated output power	KW/rpm	103/1950
Digging performance	Max. digging height	mm	9,725
	Max. dumping height	mm	6,860
	Max. digging depth	mm	6,605
	Max. vertical digging depth	mm	5,985
	Max. digging radius	mm	9,930
	Boom deflection angle	°
	Min. slew radius	mm	3,530
	Min. rear slew radius	mm	2,750
	Bucket digging force	kn	138
Track type			Steel
Track width		mm	600
Travel system	Track length	mm	4,255
	Wheel base	mm	3,462
	Track gauge	mm	2,390
	Travel spped (Gear I/II)	km/h	5.5/3.5
	Gradeability	%	70
Slew speed		rpm	13.3
Bulldozing plate	Bulldozing plate width	mm
	Bulldozing plate height	mm
	Lifting distance	mm
Hydraulic pump type			Variable pump×2
Slew motor type			Piston hydraulic motor
Travel motor type			Piston hydraulic motor
Fuel tank capacity		L	360
Hydraulic oil tank capacity		L	240
