Heating Application and silicone Insulation Material silicone high voltage wire cable
1. Brief Introduction to silicone rubber sheathed insulated 3 4 conductor cable
The silicon rubber insulated and sheathed power cable takes advantages of extruded tubing technique which improves many properties of our product, such as reliability, water proof property, resistance to acid, alkali, aging, radiance, corrosive gas as well as low temperature, etc. Meanwhile, it also offers stable performance under high temperature, and it is widely applied for harsh environment.
2. Technical Parameters for silicone rubber sheathed insulated 3 4 conductor cable
1. Rated voltage U0/U: 0.6/1kV Multi-Core Silicone Rubber Insulated Power Cable
2. Max. working temperature: 180℃
3. Min. ambient temperature for working: -60℃ for fixed laying
4. Min. ambient temperature for laying: -25℃
5. Min. bending radius: 10 times of the overall diameter
3. Related Names for silicone rubber sheathed insulated 3 4 conductor cable
Temperature Resistant Cable Manufacturer | Industrial Energy Supply | Flexible Installation Electrical Product
4. Model Explanation for silicone rubber sheathed insulated 3 4 conductor cable
| Model | Descriptions |
| YGC | Silicon rubber insulated and sheathed power cable |
| YGCR | Silicon rubber insulated and sheathed flexible power cable for movable applications |
| YGCP | Silicon rubber insulated and sheathed copper braid shielded power cable |
| YGG2G | Silicon rubber insulated and sheathed power cable with steel tape armor |
| JGG | Silicon rubber insulated and sheathed installation wire |
| JGGR | Movable silicon rubber insulated and sheathed soft installation wire |
| JGGP | Silicon rubber insulated and sheathed, copper braid shielded installation wire |
| Code | Meaning |
| Y | Series code (movable soft cable) |
| G | Silicon rubber |
| C | Heavy type |
| 2 | Steel tape armor |
| P | Copper braid shield |
| R | Multi-strand conductor |
Q/321011 KLA2003-2009: silicon rubber insulated and sheath high temperature resistant cables
8. Qualification for silicone rubber sheathed insulated 3 4 conductor cable
1. The DC resistance of R type conductor meets the requirements of GB 3956.
2. The insulation resistance at 20℃ is not lower than 100MΩ•km.
3. The finished product is able to pass the voltage withstand test without breakdown, and the test condition is AC 50Hz, 3.5kV, 5 minutes.
9. Applications for silicone rubber sheathed insulated 3 4 conductor cable
This silicon rubber insulated and sheathed power cable is suitable for fixed power transmission and portable electrical apparatus whose rated voltage is 0.6/1kV AC or lower. This product is soft, and it allows convenient laying as well as long service life. Thus, it is widely used in different fields, such as metallurgy, petrochemical product, electrical industry, electronic product, automobile manufacturing industry and others.
Packing of rubber flexible cable :
Small size 100 meters in roll, then in pallet. Big size in drums. Or as customers' request.
We will choose the right packing&shipping type according to your product specification and order quantity.
1.Pre-sale service
Offering hot-line for product and technical consultation Offering specified project design to meet the clients’ demand.
2.During-sale service
Offering training on application instruction, supervising installation condition, and debugging.
3.After-sale service
Offering 24-hour service, product upgrading or alteration, and other service.
Hebei Ronghua Wire And Cable Co.,LTD, a professional manufacture of various types rubber insulated sheath genreal rubber cable for more than 30 years experience. Surely we could provide you the factory price, stable quality and delivery in time. For any information, please kindly contact us.
Related cables:
Certification:
Production Line:
Q1:When can I get the price?
We usually quote within 6 hours after we get your inquiry. If you are very urgent to get the price, please call us or tell us in your e-mail so that we will regard your inquiry priority.
Q2.How can I get a sample to check your quality?
After price confirmation, you can require for samples to check our quality. Sample is free, but the freight charge should be paid.
Q3.How long can I expect to get the sample?
After you pay the freight charge and send us confirmed files, the samples will be ready for delivery in 3-7 days. The samples will be sent to you via express and arrive in 3~5 days.
Q4.What about the lead time for mass production?
Honestly, it depends on the order quantity and the season you place the order.The best record we keep is delivering 10 kilometers cable within a week. Generally speaking, we suggest that you start inquiry two months before the date you would like to get the products at your country.
Welcome your inquires of silicone 3 4 conductor cable. We will reply you within 12 hours!
