Help CenterHigh Accuracy Laser Diameter Gauge
Related Products
-
High Accuracy Pipe Diameter Measurung GaugeUS$ 4,000 - 4,000MOQ: 1 Piece -
Wire Diameter Measuring GaugeUS$ 3,800 - 3,800MOQ: 1 Piece
-
Two-dimensional Rubber Hose Diameter MeasurementUS$ 2,900 - 3,300MOQ: 1 Piece
-
Cable Diameter GaugeUS$ 5,000 - 10,000MOQ: 1 Piece
-
Non Contact Measurement LDM-50US$ 2,500 - 3,000MOQ: 1 Piece
Specifications
1. Laser diameter gauge2. High Accuracy 0.001 and Stability
3. Various measuring range 0.2-150mm.
High Accuracy laser diameter gauge is the high-accuracy survey installment that uses the laser scan to carry on Non-contact the on-line measure.
Mainly used in a variety of wires, cables, pipe production line, the measurement of outer diameter and adjust the extruder screw speed or traction speed, to control the purpose of OD. Can also be applied to the outer diameter of workpiece and size measurements.
1. Technical parameters
| Model | Measuring Range | Differentiation | Accuracy |
| LDM-80 | 0.2-80mm | 0.001 | ±0.02%×(Reading)±0.005mm |
LDM-150 |
0.2-150mm |
0.001 | ±0.02%×(Reading)±0.005mm |
2. The performance indicators
Measurement: Laser scanning
Laser: Visible red semiconductor laser
Laser output power: <2mW
Operating voltage: ~ 220V ± 15% 50 - 60Hz
Operating temperature: -10 ~ 40 °C
Humidity: <85% RH
Work mode: continuous
Power consumption: <30W
External dimensions:
Dimensions: LDM-80/LDM-150 Measuring head: 910mm×80mm×292mm
3. The Device with the following Characteristics:
i. Can be connected PLC, industrial computer.
ii. RROFIBUS-DP can be allocated and MODBUS converter and PLC, IPC Connect.
iii. Can be equipped remote controller DDC-3, DDC-5, on the extruder and automatic feedback control to control the tolerance, improve product quality, reducing consumption.
4. Display Controller (Model:DDC-6)
i. It be used to display and control.
ii. It Can control the speed of DC motors, VVVF motor(extruder or the tractor).
iii. It's suitbale for Laboratory use.
iv. It will alarm,when the diameter go beyond the the set tolerance.
v. With RS485 It can connect to PLC industry controlling computer.
