High Chrome and Low Chrome Cast Steel Ball For Sag Mill
1.Features of Casting Grinding Ball
1) High Hardness: surface hardness of casting balls is to 60-68 HRC and volume hardness of foundry steel balls is to 60-63 HRC;
2) High Impact Toughness: the impact toughness of high chrome grinding media is more than 12 J/cm2;
3) Low Broken Rate: the actual broken rate is not higher than 1%;
4) Wear-resistant: the grinding lost of chrome steel balls is 50-300g/ton.
2.Material and Chemical Composition of Casting Grinding Ball
Name |
Model |
Material |
C |
Si |
Mn |
Cr |
S |
P |
TITLE-8 |
High Chrome |
Cr-23-32% |
2.0-2.8 |
≤1.0 |
0.5-2.0 |
23-32 |
≤0.01 |
≤0.01 |
TITLE-9 |
Cr-18-22% |
2.0-2.8 |
≤1.0 |
0.5-2.0 |
18-22 |
≤0.01 |
≤0.01 |
|
TITLE-10 |
Cr-15-17% |
2.2-3.0 |
≤1.0 |
0.5-2.0 |
15-17 |
≤0.01 |
≤0.01 |
|
TITLE-11 |
Cr-10-14% |
2.2-3.2 |
≤1.0 |
0.5-2.5 |
10-14 |
≤0.01 |
≤0.01 |
|
TITLE-12 |
Medium Chrome |
Cr-5-9% |
2.1-3.2 |
≤1.2 |
0.5-1.5 |
5.0-9 |
≤0.01 |
≤0.01 |
TITLE-13 |
Low Chrome |
Cr-1-4% |
2.2-3.5 |
≤1.2 |
0.5-1.5 |
1.0-4 |
≤0.02 |
≤0.02 |
3.Physical Property of Casting Ball
Model |
Hardness(HRC) |
Impact Test(Ak.J/cm2) |
Endurance Test Times(5m) |
Microstructure |
|
Quenching |
Unquenching |
||||
High Chrome |
≥60 |
≥58 |
≥17 |
≥12000 |
M+C |
Medium Chrome |
- |
≥56 |
≥15 |
≥10000 |
P+C |
Low Chrome |
- |
≥53 |
≥13 |
≥10000 |
P+C |
4. Specification of Cast Grinding Ball
Nominal Diameter |
Diameter Tolerance |
Weight of Single Ball In Average |
Numbers of Per Ton Ball In Average |
|
(mm) |
(Inch) |
(mm) |
(g) |
|
20 |
0.75’’ |
+2 -1 |
32 |
31250 |
25 |
1’’ |
64 |
15625 |
|
30 |
1.25” |
110 |
9090 |
|
40 |
1.5’’ |
263 |
3802 |
|
50 |
2’’ |
513 |
1949 |
|
60 |
2.5’’ |
+3 -2 |
888 |
1126 |
70 |
2.75 |
1410 |
709 |
|
80 |
3.25’’ |
2104 |
475 |
|
90 |
3.5’’ |
2996 |
333 |
|
100 |
4’’ |
4110 |
243 |
|
110 |
4.5’’ |
+4 -2 |
5457 |
182 |
120 |
4.75’’ |
7102 |
140 |
|
130 |
5’’ |
9030 |
110 |
|
140 |
5.5’’ |
+4 -3 |
11278 |
88 |
150 |
6’’ |
13871 |
72 |
|
5.Main Process of Casting Grinding Ball
(1)Raw material (2)Scientific Proportioning (3)Electric Furnace Smelting (4)Assay Before Furnace (5)Mould Forming (6)Polishing (7)Heat Treatment (8)Qualified Products (9)Packing
6.Applied Field
1)Cement Plant 2)Mine 3)Power station 4)Chemical Industries 5)Sag Mill, Ball mill
7.Products Name
High Chrome Cast Grinding Ball,Casting Grinding Ball,Cast Iron Ball,Casting Ball,Cast Steel Ball,Cast Grinding Iron Ball,Cast Iron Grinding Ball,Cast Grinding Steel Ball,High Chrome Grinding Media,Middle Chrome Grinding media,Low Chrome Grinding Media,High Chrome Cast Ball,High Chrome Grinding Ball,Medium Chrome Casting Ball,Medium Chrome Cast Grinding Ball,Cement Mill Grinding Media, High Chrome and Low Chrome Cast Steel Ball For Sag Mill
(1) Container Bags: 1000KGS/Bag
(2) Steel Drums(with Pallet): 850-900KGS/Drum
