Product Name : Web Browsing Fingerprint Access Controller Keypad ( HF-F19)
| Introduction: |
HF-F19 is a widely used Access Control in the office. Choosing a lot of stable original parts, strictly follow the national security product standard. HF-F19 is suitable for the entrances and exits of office, factory, hotel, school, etc. All input /output are using anti-jamming protection and over-voltage/circuit protection. The product experiences the strict degradation test before leaving factory. The greatest advantage of HF-F19 is easy to install, with multifunctional & elegant design and reasonable price .
Benefits: |
· One fingerprint develop the whole world
· Adopt high reliable industrial component parts and optical sensor, watchdog monitor to avoid unit hang ,unique reset key keeps the unit well work
· Easy to install all the cable connection EM lock installation are the same to the traditional IC/ID Access control
· One-way alarm output: dismantlement alarm, threatens alarm, unlock illegally alarm, not block alarm
| Specification: |
· Operating system: Linux
· User capacity: 3000
· Transaction capacity: 100000
· Algorithm version :9.0 &10.0 algorithm
· Access Control: 50 Time Zone, 5 Grouping, 10 Combination, Holiday Management, support many fingerprints access, support standalone work
· Communicational: TCP/IP or RS232 and RS485, USB host
· Keyboard and Display: LCD with 80 character and figure keypad
· Power: 12 V DC 3A
· Identification speed: <=2 seconds
· FRR: <=1%
· FAR: <=0.0001%
· Temperature operating: 0°C - 45°C
· Humidity operating: 20%-80%
· Language: simplified Chinese, traditional Chinese, English, other Languages
· Standard: Wire Doorbell, Wiegand OUT, Wiegand IN
· Optional: ID/IC card, Webserver, Short message, Workcode, RIS,
Antipass-back
· Optional: Web-server, Work-code, RIS, Multi-identification, 9 Digits User ID, Schedule Status
· Dimension: 212.3*95.8*53.5mm
| Picture show: |
| Connection diagram: |
