This machine is suitable for automatic labeling of the vacuum blood collection tube.
Our Advantages
Good configuration, high performance
Adopt German Leuze GS photoelectric sensor, United States AB servo motor, JSCC motor and the corresponding speed drive, which have made a good fundation for the rapid, high efficient and stable labeling.
Applicable for transparent label, high efficiency, no tube stucking.
Applicable for both transparent or opaque labels. Servo motor control label sending make it rapid and stable. Give up the traditional roller filling way, adopt the unique feed way to avoid the tube stuck or breakage.
Main technical parameters and configuration
| production capacity | 12000-20000 pcs/h, (effected by label size and tube size) |
| label | both transparent and opaque label |
| tube size | ø 12 - ø 16 mm, length: 75 mm - 100 mm |
| labeling precision | ± 1 mm |
| gas consumption | ≤ 0.1 m3 / min, air source pressure: 0.5 Mpa ≤ P ≤ 0.8 Mpa; If without code device, no need gas. |
| power | 450W , AC220V |
| overall size | 2000 mm * 500 mm * 1700 mm |
| weight | 200 kg |
| Siemens touch screen | PLC, JSCC and AB motor, German LEUZE label sensor |
| others | aluminium alloy frame, parts and components are stainless steel, aluminum, etc |
Service for the production line
Pre-sale service
Sale tracking service
We will assign our experienced project manager to do the job as below:
• Sign contract
• Conform drawing
• Equipment fabricating
• Initial assembly commissioning
• Final assembly commissioning
• Ex factory inspection
• Delivery
• Final commissioning
• Inspection and acceptance
After-sale service
Our products include modular type and integral type. According to our latest design, the production line is composed of tube labeling, tube filling, gel filling, dosing, cap&stapper combining and wearing, tube pre-vacuum&loading, shrinking packing stations.
Thanks to our highly automatical advanced intelligent control system, all the fabricating information can be displayed and controlled in the touch screen, to ensure safely and effectively fabrication.
Packing |
Export standard package |
MOQ |
1 set |
FOB price |
Please contact for new price |
Delivery time |
60days |
FOB port |
Shanghai |
Payment terms |
T/T,L/C at sight |
