Home > Products > New Products > 80Kva Cummins Silent Genset, Powered by Cummins 6BT5.9-G2 Engine Quality Choice

80Kva Cummins Silent Genset, Powered by Cummins 6BT5.9-G2 Engine Quality Choice

Name: 80Kva Cummins Silent Genset, Powered by Cummins 6BT5.9-G2 Engine Quality Choice
Brand: 80kva Cummins silent genset
Availability: InStock

FOB Price

US$ 7,000 - 10,500 / Set

1 Set(Min. Order)

Port Shanghai
Payment TermsT/T Credit Card

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Jiangsu, China	Brand Name	80kva Cummins silent genset
Model Number	6BT5.9-G2	Output Type	AC Three Phase
Speed	1500rpm/min	Frequency	50Hz
Rated Power	80Kva	Rated Voltage	110V~600V
Rated Current	115.2A

Product Description

Specifications

80kva Cummins silent genset, powered by Cummins 6BT5.9-G2 engine
Stamford alterantor
Deepsea control panel
High quality

80Kva Cummins silent genset (Engine model: 6BT5.9-G2)

Main technical data

Cummins engine-6BT5.9-G2

Every generator set is subjected to a comprehensivetest program which includes 50% load, 75% load,100% load, 110% load and the checking and proving of all control and safety shut-down functions;

24V DC start motor;

Equipped with battery charger and 24V highperformance maintenance-free lead-acid startingbatteries and connecting with cables;

Equipped with industrial silencer and flexible exhaust hose;

Equipped with CHINT MCCB circuit breaker;

Designed to Comply with ISO8528/GB2820;

Powered by Cummins engine,Controlled by Deepsea panel

Voltage

Phase

P.F

(COS)

Output

(KVA)

400/230V

0.8

Remark

60Hz, 220, 380V, 460V, 480V, 600V can be produced as requirements.

Engine

Cummins diesel generator power capacity

Engine Model	6BT5.9-G2
Number of Cylinders	6 cylinders in line
Cycle	4 stroke
Aspiration	Turbocharged and after water cooled
Bore×Stroke	102mm x120mm
Displacement	5.9L
Compression ratio	17.5:1
Prime Power/Speed	86KW / 1500rpm
Standby Power/Speed	92KW / 1500rpm
Speed Governor	Electrical
Cooling System	Forced water cooling cycle
Steady speed droop	≤1%
Total lubrication system capacity	16.4L
Coolant capacity (engine only)	9.1L
Fuel Consumption at 100% Load	208g/kw.h
Starter Motor	DC24V,
Alternator	DC24V

Alternator

Alternator brand	Stamford, Marathon, Leroy Somer, Mecc-alte, TWGII…
Prime power	80Kva
Frequency/speed	50HZ/1500rpm (60Hz/1800rpm)
Exciter type	Single bearing, Brushless, Self-excited
Power factor	0.8
Voltage adjust range	≥5%
Voltage regulation NL-FL	≤±1%
Insulation Grade	H
Protection Grade	IP23

Control panel

The control module gives digital readouts of:

Generator voltage;

Output frequency;

Engine speed;

Battery voltage;

Engine hours run.

The control module has indicators for failure

information:

Overspeed/underspeed,

Emergency stop

Low oil pressure;

High water temperature

Failure to start

Battery charger failure

Automatic shutdown occurs under:

Low engine oil pressure;

High engine water temperature;

Overspeed/underspeed;

Failure to start after three attempts.

Pictures FYI

100Kva Cummins silent diesel generator

100Kva Cummins silent diesel generator (Packing)
