automatic dosing machine
- 10 Set / Sets per Month
- shanghai
- T/T
- Packaging linkage line Pharmaceuticals industrypackaging production line
- Logistics industrybox and palletizing assembly line
- Hardware fittingpackaging assembly line Foodstuffvertical packaging line
- Food service industryback road packaging production line
- Logistics industrybox and palletizing production line Box and palletizing assembly line
- Coffeetriangle packaging linkage line
Product Details
Condition: | New | Application: | Other, Medical, Machinery & Hardware, Medical | Packaging Type: | Case |
Packaging Material: | Wood | Automatic Grade: | Automatic | Driven Type: | Electric |
Voltage: | AC380V, 50/60 Hz | Power: | 3.6kw | Place of Origin: | Shanghai, China |
Brand Name: | H-Dynamic | Model Number: | JYJ03 | Dimension(L*W*H): | 1200 mm * 1000 mm * 1800 mm |
Weight: | 400kg | Certification: | GMP/CE | After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
It is suitable for reagent precise filling and spraying of blood collection tube
Our Advantages
High accuracy and stability
Adopt advanced and stable plunger pump filling way, precision reaches 1%, not affected by pressure, voltage and time.
Automatic alarm, blockage prevention
During the process of filling and spraying, the medicament crystal will block the nozzle and it’s hard to be discovered in the traditional operation process, the check process is complicated. In order to solve this problem, this equipment adopts a set of automatic alarm system, when the blocking of spraying nozzle, line caused by foreign body or crystal under half, it does not affect the filling precision and spraying, while the blocking is over half, the equipment will automatically alarm immediately.
Easy operation
Drug dose can be directly adjusted on touch screen, if you need 20ml medicine, just set the dosage on the touch screen as 20, no need adjust the pressure, time, etc. If choose a rate volume pump, no need to adjust. This machine also equipped with drying system, can select on or off according to process requirements.
Main technical parameters and configuration
Production capacity | 12,000-25,000 pcs/h, (depends on different processes) |
Filling heads | 2 or 4 nozzle (charging system, quantity is optional), 2/4 pcs/ time |
Charging quantity | ration: 10 uL/time, 20 uL/time, 200 uL/time, 400 uL/time (anticoagulant / coagulant); Non-ration: 10-40 ul/time |
Control precision | ≤±1%F |
Tube type | Φ 13 tube (3*75,13*100) or Φ 16 tube;(the tube clamp for Φ 13 and Φ16 is not universal) |
Gas consumption | ≤ 0.2m3 / min, 0.5mpa≤P≤0.8Mpa |
Power | 3.6 KW, AC380V, 50/60 Hz |
Overall size | 1200 mm * 1000 mm * 1800 mm |
Weight | 400kg |
Service for the production line
Pre-sale service
Sale tracking service
We will assign our experienced project manager to do the job as below:
• Sign contract
• Conform drawing
• Equipment fabricating
• Initial assembly commissioning
• Final assembly commissioning
• Ex factory inspection
• Delivery
• Final commissioning
• Inspection and acceptance
After-sale service
Our products include modular type and integral type. According to our latest design, the production line is composed of tube labeling, tube filling, gel filling, dosing, cap&stapper combining and wearing, tube pre-vacuum&loading, shrinking packing stations.
Thanks to our highly automatical advanced intelligent control system, all the fabricating information can be displayed and controlled in the touch screen, to ensure safely and effectively fabrication.
Packing | Export standard package |
MOQ | 1 set |
FOB price | Please contact for new price |
Delivery time | 60days |
FOB port | Shanghai |
Payment terms | T/T,L/C at sight |
