Help Center50kva Generator Powered by 4BTA3.9-G2 Engine With Perfect Technology
Related Products
-
80Kva Generator, Powered by 6BT5.9-G2 EngineUS$ 7,000 - 10,500MOQ: 1 Set -
250Kva Genset, Powered by Cummins NT855-GA EngineUS$ 7,000 - 10,500MOQ: 1 Set
-
80Kva Genset, Powered by Cummins 6BT5.9-G2 EngineUS$ 7,000 - 10,500MOQ: 1 Set
-
250Kva Silent Generator, Powered by Cummins NT855-GA Engine, Super Silent TypeUS$ 7,000 - 10,500MOQ: 1 Set
-
80Kva Silent Generator, Powered by 6BT5.9-G2 EngineUS$ 7,000 - 10,500MOQ: 1 Set
Specifications
50kva generator powered by 4BTA3.9-G2 engine at 50hz 1500rpmStamford alterantor
Deepsea control panel
High quality
50kva generator powered by Cummins engine
Cummins series diesel generator is adopted the B, N, K series engine(sino-us), and widely used in army, engineering, mining industry, more reliable, economic. Cummins company was founded in 1919, the H.Q is in Columbus, indiana (USA), and have about 500 distributors spread in 190 countries and regions, users can have the very efficient service, fast connection with the company. As the top one of JVC in China diesel generator set industry, Dongfeng Cummins Engine Co,Ltd(for B,C,L series) & Chongqing Cummins Engine Co., Ltd(for M,N,K series) are it's branches.
Every generator set is subjected to a comprehensivetest program which includes 50% load, 75% load,100% load, 110% load and the checking and proving of all control and safety shut-down functions;
24V DC start motor;
Equipped with battery charger and 24V highperformance maintenance-free lead-acid startingbatteries and connecting with cables;
Equipped with industrial silencer and flexible exhaust hose;
Equipped with CHINT MCCB circuit breaker;
Designed to Comply with ISO8528/GB2820;
Powered by Cummins engine,Controlled by Deepsea panel
Voltage |
HZ |
Phase |
P.F (COS) |
Output (KVA) |
400/230V |
50 |
3 |
0.8 |
25 |
Remark |
60Hz, 220, 380V, 460V, 480V, 600V can be produced as requirements. |
|||
Performance Index
Sutech power Co., Ltd is the most professional manufacturer in diesel generator industry. All our products are composed by the generators that well equipped with famous brand engines, brushless self-excitation AVR controller, and have a complete range of sizes to meet the different demands of clients. The diesel generator sets usually work with 400V / 230V three-phase four-wire system and 50HZ AC, the 60HZ AC or other voltage standard used in worldwide is also acceptable..
Standard Power
Rated voltage: 400/230V 3 phases and 4 wires
Rated frequency: 50HZ (60HZ)
Atmospheric pressure: 1000KP (ALT 1000m)
Ambient temperature: 5 ℃ -45 ℃
Relative Humidity: 60%
Reliable operating status: ALT is under 1,000 meters; AT is 45℃.
Engine Model |
4BTA3.9-G2 |
Engine manufacturer |
Cummins |
Number of Cylinders |
4 cylinders |
Cylinders arrangement |
Vertical in line |
Cycle |
4 stroke |
Aspiration |
Naturally |
Bore×Stroke |
102mm x120mm |
Displacement |
3.9L |
Compression ratio |
16.5:1 |
Prime Power/Speed |
50KW / 1500rpm |
Standby Power/Speed |
55KW / 1500rpm |
Speed Governor |
electrical |
Cooling System |
Forced water cooling cycle |
Steady speed droop |
≤1% |
Total lubrication system capacity |
11L |
Coolant capacity (engine only) |
7.2L |
Fuel Consumption at 100% Load |
210 g/kw.h |
Starter Motor |
DC24V, |
Alternator |
AC24V |
Alternator brand |
Stamford, Marathon, Leroy Somer, Mecc-alte, TWGII… |
Prime power |
50Kva |
Frequency/speed |
50HZ/1500rpm (60Hz/1800rpm) |
Exciter type |
Single bearing, Brushless, Self-excited |
Power factor |
0.8 |
Voltage adjust range |
≥5% |
Voltage regulation NL-FL |
≤±1% |
Insulation Grade |
H |
Protection Grade |
IP23 |
The control module gives digital readouts of:
Generator voltage;
Output frequency;
Engine speed;
Battery voltage;
Engine hours run.
The control module has indicators for failure
information:
Overspeed/underspeed,
Emergency stop
Low oil pressure;
High water temperature
Failure to start
Battery charger failure
Automatic shutdown occurs under:
Low engine oil pressure;
High engine water temperature;
Overspeed/underspeed;
Failure to start after three attempts.
Packaging:plywood case
Shipping:From Shanghai
12 months or 1000 hours of warranty time for all our products. We take the full responsibility only in the fault that created by the quality,the wearing-parts, daily consumables and human error of operating and maintenance are not included in.
Before sales service
Free charge on load capacity analysis, complete-set forming, technology consultation as well as assisting user to fix up machinery room and lay out equipment installation plan.
Under sales service
For the purpose of helping user to master all type of generator operation, use and maintenance better, we specially offer the cost-free full set on-site training session in our company
After sales service
We attach great importance of after sale service,we establish the computer backup for follow up service and periodic inspection. Our Maintenance Center has the quick rection management system, we’ll indicate user eliminate fault in an hour via phone or arrange the service people doing on-site maintenance A.S.A.P for more complicated condition. About the complain,we always strictly follow the principle of seeking truth, and appoint the responsible person to solve trouble.
Sutech Power Co., Ltd
No.18 Hailing Industry Park, Taizhou City, Jiangsu Province, China
Mobile: +86-18262802979
skype:jsad0911
