300kw low price soundproof diesel generator welding machine
- 30 Set / Sets per Month
- Shanghai
- T/T Credit Card
Product Details
Place of Origin: | Jiangsu, China | Brand Name: | 300kw 2206C-E13TAG2 generator | Model Number: | 2206C-E13TAG2 |
Output Type: | AC Three Phase | Speed: | 1500rpm/min | Frequency: | 50Hz |
Rated Power: | 300KW | Rated Voltage: | 380/220V | Rated Current: | 540A |
Product Description
300kw low price soundproof diesel generator welding machine
(High quality, Original engine, Low fuel consumption)
Powered by Perkins engine
Every generator set is subjected to a comprehensivetest program which includes 50% load, 75% load,100% load, 110% load and the checking and proving of all control and safety shut-down functions;
24V DC start motor;
Equipped with battery charger and 24V highperformance maintenance-free lead-acid startingbatteries and connecting with cables;
Equipped with industrial silencer and flexible exhaust hose;
Equipped with CHINT MCCB circuit breaker;
Designed to Comply with ISO8528/GB2820;
Powered by UKP engine,Controlled by Deepsea panel
Voltage | HZ | Phase | P.F (COS) | Output (KVA) |
380/220V | 50 | 3 | 0.8 | 375 |
Remark | 60Hz, 220, 380V, 460V, 480V, 600V can be produced as requirements. |
300kw silent 2206C-E13TAG2 generator with original Perkins engine
Engine Model | 2206C-E13TAG2 |
Number of Cylinders | 6 cylinders, vertical in line |
Cycle | 4 stroke |
Aspiration | Turbocharged and after water cooled |
Bore×Stroke | 130mm x157mm |
Displacement | 12.5L |
Compression ratio | 16/3:1 |
Prime Power/Speed | 305KW / 1500rpm |
Standby Power/Speed | 349KW / 1500rpm |
Speed Governor | Electrical |
Cooling System | Forced water cooling cycle |
Steady speed droop | ≤1% |
Total lubrication system capacity | 40L |
Coolant capacity | 51.4L |
Fuel Consumption at 100% Load | 209g/kw.h |
Starter Motor | DC24V, |
Alternator | DC24V |
Alternator brand | Stamford, Marathon, Leroy Somer, Mecc-alte, TWGII… |
Prime power | 375KVA |
Frequency/speed | 50HZ/1500rpm (60Hz/1800rpm) |
Exciter type | Single bearing, Brushless, Self-excited |
Power factor | 0.8 |
Voltage adjust range | ≥5% |
Voltage regulation NL-FL | ≤±1% |
Insulation Grade | H |
Protection Grade | IP23 |
Phase / wire | 3 phase 4 wires |
The control module gives digital readouts of:
Generator voltage;
Output frequency;
Engine speed;
Battery voltage;
Engine hours run.
The control module has indicators for failure
information:
Overspeed/underspeed,
Emergency stop
Low oil pressure;
High water temperature
Failure to start
Battery charger failure
Automatic shutdown occurs under:
Low engine oil pressure;
High engine water temperature;
Overspeed/underspeed;
Failure to start after three attempts.
Soundproof for optional
