15KW silent generator set, powered by Yangdong YD480D
Stamford alterantor
Deepsea control panel
High quality
Every generator set is subjected to a comprehensivetest program which includes 50% load, 75% load,100% load, 110% load and the checking and proving of all control and safety shut-down functions;
24V DC start motor;
Equipped with battery charger and 24V highperformance maintenance-free lead-acid startingbatteries and connecting with cables;
Equipped with industrial silencer and flexible exhaust hose;
Equipped with CHINT MCCB circuit breaker;
Designed to Comply with ISO8528/GB2820;
Powered by YangDong engine,Controlled by Deepsea panel
Voltage |
HZ |
Phase |
P.F (COS) |
Output (KW) |
110V |
60 |
1 |
0.8 |
15 |
Remark |
60Hz, 220, 380V, 460V, 480V, 600V can be produced as requirements. |
|||
YangDong diesel generator power capacity
Engine Model |
YD480D |
Number of Cylinders |
4 cylinders, Vertical in line |
Cycle |
4 stroke |
Aspiration |
Naturally and after water cooled |
Bore×Stroke |
80mm x90mm |
Displacement |
1.8L |
Compression ratio |
22:1 |
Prime Power/Speed |
16KW / 1800rpm |
Standby Power/Speed |
18KW / 1800rpm |
Speed Governor |
electrical |
Cooling System |
Forced water cooling cycle |
Steady speed droop |
≤1% |
Total lubrication system capacity |
6L |
Coolant capacity (engine only) |
8.5L |
Fuel Consumption at 100% Load |
5.2L |
Starter Motor |
DC12V, |
Alternator |
DC12V |
| Engine | Yangdong |
Alternator brand |
Stamford, Marathon, Leroy Somer, Mecc-alte, TWGII… |
Prime power |
15KW |
Frequency/speed |
60Hz/1800rpm |
Exciter type |
Single bearing, Brushless, Self-excited |
Power factor |
0.8 |
Voltage adjust range |
≥5% |
Voltage regulation NL-FL |
≤±1% |
Insulation Grade |
H |
Protection Grade |
IP23 |
Phase / wire |
1 phase |
Control Panel
The control module gives digital readouts of:
Generator voltage;
Output frequency;
Engine speed;
Battery voltage;
Engine hours run.
The control module has indicators for failure
information:
Overspeed/underspeed,
Emergency stop
Low oil pressure;
High water temperature
Failure to start
Battery charger failure
Automatic shutdown occurs under:
Low engine oil pressure;
High engine water temperature;
Overspeed/underspeed;
Failure to start after three attempts.
