XPS foamed board extrusion production line is one of our hi-tech products first successfully
developed and sold in China. Depending on continuous improvement and updation, our
technical level keeps leading position in China. Ps foamed board is one kind of good insulating
materials with continuous even surface and beehive structure. It has superior advantages of heat
preservation, heat insulation, waterproofness and high compression resistance. XPS board has
been widely used in the fields of heat preservation and insulation for roof and outer wall, low
temperature storage facilities, surface and undersurface of roads. As an ideal heat insulating
and dampproof material, it has wide market prospect.
Detailed Parameters:
1)Used PS material to extrude the foamed board for insulation construction field,
2)Outlook complete and unify, SIEMENS PLC digital control,
3)The die mould accuracy, the runner more reasonable,
4)The recirculating water tank of cast aluminum cooling system,
5)Large output with stable working performance
6)The self-contained auxiliary machines for your different production plan.
Model |
Screw diameter and L/D ratio |
Board |
Capacity |
Power |
||
Width/mm |
Thickness/mm |
Density |
||||
SFBZ-100/120 |
Single screw 100-32D Single screw 120-35D |
600 |
20-70 |
32kg/m3 |
180m3/d |
180kw |
SFBZ-135/150 |
Single screw 135-32D Single screw 150-42D |
600/900/1200 |
20-120/80/60 |
30kg/m3 |
350m3/d |
260kw |
SFBZ-75/150 |
Twin screw 75-32D Single screw 150-42D |
600/900/1200 |
20-120/80/60 |
30kg/m3 |
360m3/d |
280kw |
SFBZ-170/200 |
Single screw 170-30D Single screw 200-34D |
600/900/1200 |
20-150/150/80 | 28kg/m3 |
450m3/d |
520kw |
