PPR Pipe Extruding Production Line

PPR Pipe Extruding Production Line thumbnail-1
PPR Pipe Extruding Production Line thumbnail-2
PPR Pipe Extruding Production Line photo-1
PPR Pipe Extruding Production Line photo-2
US$ 250,000 - 350,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Type:
Pipe Production Line
Pipe Material:
PP
Contact Supplier Request Quote Chat Now
Qingdao Deyili Plastic Machinery Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao CHINA
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Type Pipe Production Line
Pipe Material PP
Application Energy Supply Pipe
Production Capacity 180kg per hour
Place of Origin Shandong, China
Brand Name DEYILI
Model Number DPPR-63
Voltage 380v
Power(W) 120kw
Dimension(L*W*H) 37*3*3m
Weight 20tons
Certification CE ISO
Warranty 1 year
After-sales Service Provided Engineers available to service machinery overseas

 Features of  PPR Pipe Extruding Production Line:

PPR Pipe Extruding Production Line

Product Description



1) Based on latest German technology, designed for extrusion of PPR pipes. The quality of pipes is tested to be in compliance with the ISO-DIS 15874-22-98 standards.
2) Specially designed high efficient extruder for PPR: Equipped with imported reducer, grooved feed bush and BM screw which allow great output, lower melting temperature and lower energy consumption.
3) Mould and die co-extrusion spiral die assures adequate material flow and more even internal pressure distribution and a static mixing system for option.
4) Stable calibrator: Vacuum calibration and optimum cooling result due to special design and multi-section water membrane cooling which meets the requirements of thicker waft pipe or larger diameter pipe extrusion with high speed.
5) Quality component reducer of extruder, DC speed regulator, frequency converter, PLC control system and jet printer are all imported.

Main technical parameter:

Model

Pipe Range

Extruder Model

Power

Max. capacity

DPPR-63

20-63mm

DS-65-34

120kw

180kg/h

DPPR-110

20-110mm

DS-80-34

220kw

280kg/h

DPPR-160

63-160mm

DS-80-34

230kw

280kg/h





Packaging

Packaging

Standard sea-worthy package mainly with wood pallets& film

and some parts in plywood. In 1 40' containers.



Our Services

 1

Customize Design: Special design for every customer’s actual needs

 2

Guarantee of quality: One year guarantee of quality for line under correct operation.

 3

Documents supply: Mechanical and electrical operation manual, Electrical connection

drawing(1)and Operation technique manual(1).

 4

After-sales service provided: Engineers team available to service machine overseas.

 5

Machine maintenance: Machine lifelong maintenance while troublesome happens.

6

Upgrade: Free production software upgrading production formula, process technology and

machine structure improves, etc.



Our Factory

PPR Pipe Extruding Production Line

Frequent questions

Payment terms

30% down payment after signing the contract within 5 workdays,

the rest 70% payment after test run in our factory and before shipment.

Accepting& inspecting

 in seller's factory

Bring into the agreed time, it is in seller's factory to accept and inspect.

The test run will make the pipes under two sides discussion, and

promise the machine works in succession for two hours.

Other special request, negotiate by two sides.

The charge of test materials should be paid by buyer side.

Installation&test-run

in buyer's factory

1)User should prepare the plant, operators and tools for machine

installing, and make the energy available such as water, electricity,

materials, work space, labors and so on.

2)Seller send one engineer for direction and supervising the

installing, test run and training. The test run will be finished in 15 days

if there is other requests please inform in advance.

3)The buyer should pay $100 per day as subsidy for the engineer, and

in addition the round airplane tickets, food, hotel fee and insurance of

the engineer during the installation and test-run period.

Documents supply

Mechanical and electrical operation manual(1),

Electrical connection drawing(1),

And Operation technique manual(1).



Welcome for your visiting and discuss the details on the technical and process.

The concrete information please write to our sales.
