FLP-12D PLC Controlled Piston Filling Machine

FLP-12D PLC Controlled Piston Filling Machine thumbnail-1
FLP-12D PLC Controlled Piston Filling Machine photo-1
Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
New
Application:
Other
Packaging Type:
Bottles
Contact Supplier Request Quote Chat Now
Nanjing Rinchen International Trading Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Application Other
Packaging Type Bottles
Automatic Grade Automatic
Power 1.5KW
Place of Origin Jiangsu, China
Brand Name no
Model Number FLP-12D

Specifications

This filling machine is suitable for liquid without carbonated, semifluid qualitative filling.

Main characteristics:
This filling machine is suitable for liquid without carbonated, semifluid qualitative filling. Counting of bottles inlet qualitative filling, bottles outlet is done automatically. Especially suitable for SL, EC, SC, edible oil, lubrication oil. It is an ideal equipment for foodstuff, medical, cosmetic, fine chemical, pesticide industries.
1. It adopts advanced mechanical and electrical integration technology. Any filling specification can easily be done by changing parameters in touch screen. Not only the filling volume of 12 filling heads can be changed substantially, but also each filling head can be changed finely.
2. With touch screen technologies, which make operation of machine steadier, convenient, the human machine interface is more friendly. Photoelectric sensor, approaching switch and other elements are using international famous brand. No bottle no filling, the machine can stop automatically and alarm when bottles get blocked.
3. It uses the method of submerging filling; various sealing rings used can meet different characteristics of products requirements.
4. The design and production of this machine is in accordance with GMP standard requirements. Easily dismantle, clean and maintain. The parts which contact filling products are made of high quality stainless steel. The whole machine is safe, environmental, sanitary, adapting to various kinds of working places.


Technical parameter:
No.
Items
Performance
01
Machine dimension (L×W×H)
2000mm×1100mm×2200mm
02
No. of filling head
12
03
Suitable bottle size
Diameter
φ40mm~φ100mm
Height
80mm~300mm
04
Diameter of bottle mouth
≥φ18mm
05
Filling range
50ml~1000ml
06
Production capacity
≤ 6000 bottles/hour  (tested by water)
07
Tolerance of filling
50ml ~ 100ml
±1%
100ml~ 500ml
±0.5%
500ml ~ 1000ml
±0.3%
08
Voltage
220V; 50Hz
09
Power
1.5kW
10
Air consumption
0.55 - 0.65 Mpa clean and stable compressed air
