Home > Products > Stretch Film Machine > Machine Making Stretch Film Roll, Single-layer Stretch Film Making Machine
Machine Making Stretch Film Roll, Single-layer Stretch Film Making Machine
- NINGBO OR SHANGHAI
- T/T
You May Like
Product Details
| Condition | New | Application | Film | |
| Plastic Processed | PE | Screw Design | Double-screw | |
| Automatic Grade | Automatic | Place of Origin | Zhejiang, China | |
| Brand Name | JINGDIANRUIHUA | Model Number | DFA-600/1000 | |
| Voltage | 3Phase 4Line 380V 50Hz | Power(W) | 15kw | |
| Dimension(L*W*H) | 5600*1500*1800mm | Weight | 2200kgs | |
| Certification | CE SGS | After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Machine Making Stretch Film Roll, Single-layer Stretch Film Making Machine
Use:
--Machine Making Stretch Film Roll, Single-layer Stretch Film Making Machine uses LLDPE as main material and adopts several kinds of resins to manufacture the single/double-side self-sticky stretch wrapping film.
--The film has good tensile strength,anti-pricking ability and impact strength. Its good shrinking memory function and self-sticky can make goods integrity to prevent goods from loosening and collapsing during transportation and being polluted by dust. The transparency and tensile strength of this product can make the packaging beautiful, economical and practical.
--The film can be widely used in wrapping of palletized goods. It’s a good substitute for hot shrinking packaging film during transportation
Main Technical Variables:
Model: | DF-600double-side sticky | DF-1000 double-side sticky |
Screw Diameter | 55mm | 65mm |
L/D ratio | 28:1 | 28:1 |
Rationl speed of screw stem | 10-120rpm | 10-120rpm |
Screw Barrel Material | 38CRMOLA | 38CRMOLA |
Die width | 750mm | 1250mm |
Film Width | 600mm | 1000mm |
Thickness | 0.015-0.04mm | 0.015-0.04mm |
Rollout Diameter | 300mm | 300mm |
Output | 30kg/h | 50kg/h |
Main Motor Power | 11kw | 15kw |
Heating Power | 15kw | 25kw |
Overall dimension: | 6000x1500 x2500mm | 6000x2000 x2500mm |
Total Weight | 3000kg | 4000kg |
