FRP Pipe Making Machine
Brief introduction of GRP/FRP continuouos winding pipe production line
Our Deyili Group launch the latest new products GRP continuous winding pipe production line.
The production line adopts continuous winding arts technics and curing process: winding, feeding,
solidifying, sustaining, anti-twisting, cutting, unloading, a train of automatic secessive production line.
It has much more advantages of advance technics, high automatic, high output, a wide range of
production specifications, this technology filled the gaps in the international field. And the products
is researched and developed by Deyili ourself, and has full-autonomy property rights.
1)Used composite material to winding pipe for energy transport, industrial water and irrigation system,
2)The machine high automatic and SIEMENS PLC control,
3)Production speed high, raw material utilization high and cost low,
4)Adopts continuous winding technology and own mechanical patant of invention,
5)Good working condition and stable performance,
6)Stable pipe quality and easy connection of sleeve coupler.
Model |
Pipe Range |
Power |
Producing Speed |
DGL-1600 |
600-1600 |
160kw |
8-22m/h |
DGL-2600 |
800-2600 |
180kw |
5-20m/h |
DGL-3000 |
800-3000 |
205kw |
4-20m/h |
This GRP production line is wholly researched and developed by Longtech brand, and it is owned
intellectual property rights by themselves. After completely absorption the foreign technology, our
company has successfully developed the GRP continuous winding pipe production line on Ø800-
1600/2600/3000mm.
This production line is of high productivity, small dimension, well production environment, but also
with the PLC programmable control system to maximize the performance, and achieved good results
in the mechanical and electrical integration.
Packaging |
Standard sea-worthy package mainly with wooden pallet and film coverage for the main machine body; wooden cases for electrical parts & consumable parts. In 9 40' containers. |
1 |
Customize Design: Special design for every customer’s actual needs |
2 |
Guarantee of quality: One year guarantee of quality for line under correct operation. |
3 |
Documents supply: Mechanical and electrical operation manual, Electrical connection drawing(1)and Operation technique manual(1). |
4 |
After-sales service provided: Engineers team available to service machine overseas. |
5 |
Machine maintenance: Machine lifelong maintenance while troublesome happens. |
6 |
Upgrade: Free production software upgrading production formula, process technology and machine structure improves, etc. |
Deyili passed certifications of ISO9001 and CE. According to criteria of modern enterprises, we are
making great efforts to carry out effective management from production, supply, quality, technique, to
services. Deyili has won wide recognition from domestic and overseas customers by high quality products
and service.
After years of exploration, the enterprise has been enlarged and strengthened continuously. Now it has
become a group which widened its businesses from one fold plastic machinery to production of plastic
pipes and pipe-fittings. Deyili can provide more integrated solutions and all-around services to customers
from extrusion lines to technique and materials.
Payment terms |
30% down payment after signing the contract within 5 workdays, the rest 70% payment after test run in our factory and before shipment. |
|
Accepting& inspecting in seller's factory |
Bring into the agreed time, it is in seller's factory to accept and inspect. The test run will make the pipes under two sides discussion, and promise the machine works in succession for two hours. Other special request, negotiate by two sides. The charge of test materials should be paid by buyer side. |
|
Installation&test-run in buyer's factory |
1)User should prepare the plant, operators and tools for machine installing, and make the energy available such as water, electricity, materials, work space, labors and so on. 2)Seller send one engineer for direction and supervising the installing, test run and training. The test run will be finished in 15 days if there is other requests please inform in advance. 3)The buyer should pay $100 per day as subsidy for the engineer, and in addition the round airplane tickets, food, hotel fee and insurance of the engineer during the installation and test-run period. |
Documents supply |
Mechanical and electrical operation manual(1), Electrical connection drawing(1), And Operation technique manual(1). |
Welcome for your visiting and discuss the details on the technical and process.
The concrete information please write to our sales.
