SINOTRUK HOWO water truck spray gun shape can be adjustable low price water tank trucknk trucks
| ||||
Model Name |
Sinotruk HOWO 6x4 water truck |
|||
Driving Type |
6*4,left hand drive |
|||
Weights | ||||
Payload (kg) |
30000 |
|||
Curb weight(kg) |
11970 |
|||
Dimensions | ||||
Wheelbase(mm) |
4325+1350 |
|||
Overall Dimension(mm) |
9320*2496*3200 |
|||
Water tanker size |
20000L |
|||
Max speed(km/h) |
90 |
|||
Engine | ||||
Engine model |
WD615.92 (266HP) |
|||
Engine type |
Diesel 4-storke, Inter-cooling,water-cooling,turbo-charging |
|||
No. of cylinders |
straight-6 cylinders |
|||
Displacement(L) |
9.726L |
|||
Max. output (kw) |
196kw/2200rpm |
|||
MaxTorque(N*m)/Rev(r/min) |
1100/1100-1600 |
|||
Drive Line | ||||
Transmission |
Model:HW13710, Speed range:10 forwards, 2 reverse gear,manual operation |
|||
Steering |
ZF8098 Power steering |
|||
Brake system |
Service braking,dual circuit compressed air brake;Parking brake(hand brake);spring energy air cut brake.ratio:5.73 |
|||
Cab | ||||
Cab |
HW76 |
|||
Standard configuration |
Air container,oil pressure gauge, air pressure,fule level indicator,battery charge indicator,Temperature indicator ,,thermometer, Hopper drive switch for operation and so on |
|||
Axle | ||||
Front axle |
HF7(7tons) |
|||
Rear axle |
HCY13 |
|||
Tire specification | ||||
Tire specification |
12.00-20 standard tire |
|||
Tire quality |
10 tires+1 spare tire |
|||
Box information | ||||
Water tanker material |
Of high quality carbon steel (Q235) |
|||
Introduction |
1. Suction≥7m Sprinkler width≥14m Range≥28m 2. with front spout, back spill and side spout function 3. with the working platform at the back, wich can be installed green high-pressure water spray gun.(The spray gun shape can be adjustable: heavy rain, moderate rain, drizzling rain or haze.) 4. Provide the best high-power sprinkle pumps quality of the national,And with fire coupling, self-flow add self- priming function. |
|||
Sprinkling area(m) |
|
|||
Watering pressure |
|
|||
Manhole |
Man way access hole on top of tank;1 units DN500mm manhole |
|||
Front spray function |
Front spray bar with fan sprayer on both sides, spray range: »28m |
|||
Man walk way |
With skid resistance man walk way on top of tank |
|||
| Horse reels | Two 75 ft hose reels at each side of the truck | |||
| Water pump |
Water pump model: CLW80QZF-60/90N (N/S) Water pump flow rate(L/m): 60m3/h Head of delivery(m): 90m Self-priming function(min/4m):1.56 Efficiency(%):95% Related rotate speed(r/min)1180 matched power(kw):22 |
|||
| Other | ||||
Electric system |
VDO electric system ,24V,negative grouped | |||
| Tool | Standard equipment | |||
