Home > Products > Air Bubble Film Machine > Air Bubble Film Making Machine
Air Bubble Film Making Machine
- ningbo port shanghai port
- T/T Credit Card PayPal
You May Like
Product Details
| Condition | New | Application | Film | |
| Plastic Processed | PE | Screw Design | Double-screw | |
| Automatic Grade | Automatic | Place of Origin | Zhejiang, China | |
| Brand Name | JINGDIANRUIHUA | Model Number | DFPEG-1200 | |
| Voltage | 220v50HZ | Power(W) | 55kw | |
| Dimension(L*W*H) | 7.5m*2.5m*2.5m | Weight | 3.8T | |
| Certification | CE/SGS | After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Air Bubble Film making machine
Feature:
1.This machine adopts once through shaping technique,thus has high efficiency
and excellent product quality.
2.This machine set has such feature as scientific and reasonable structure design,
smooth and realiable running and convenient operation and maintenance.
3.Polyethylene air cushion film(also called polyethylene bubble film),which is divided into
two kind:ordinary polyethylene air-cushion film and composite polyethylene air cushion film,is a kind of packing material which has been widely used at present.
4.It not only has good cushioning effect,shock resistance and heatsealing performance,
but also has such advantages as good corrosion resistance and transparency,etc.
5.So it has been sidely used for packing household wares,post parcel,prcise instrument,bicycle,polyurethane furniture,etc.
Main Technical Variables:
Model | DFPEG-1500 | DFPEG-1200 | DFPEG-1000 | DFPEG-600 | ||
Main and auxiliary extruder screw diameter | φ75mm | φ65mm | φ65mm | φ55mm | ||
L/D | 28:1 | 28:1 | 28:1 | 28:1 | ||
Main and auxiliary extruder electrical power | 18.5KW | 15KW | 15KW | 11KW | ||
Width of production | 1500 mm | 1200 mm | 1000mm | 600 mm | ||
Main bubble specification(arbitrary eligibility) | φ6×3.2mm φ10×3.4mm φ25×10mm φ30×10mm | |||||
Output | 50-80kg/h | 30-60kg/h | 30-50kg/h | 20-40kg/h | ||
Totalinstalled capacity | 65kw | 55kw | 45kw | 40kw | ||
Overall dimension | 7.5m×2.8m×2.5m | 7.5m×2.5m×2.5m | 7.5m×2.3m×2.5m | 7.0m×2.0m×2.5m | ||
Gross weight | 5.0T | 3.8T | 3.5T | 2.8T | ||
Parts for choice . automatic feeding . electrical screen filter changer .automaticoverturn rewinder | ||||||
