overmoulding plastic injection mould tooling mold mold fabrication process overmoulding

1.Quotation

To meet your needs

          ↓

2.Discussion

Mold material, cavity number, price, runner, payment, etc.

          ↓

3.S/C Signature

As your requirement

          ↓

4. Payment

Pay 50% by T/T advanced

          ↓

5.Product Design Checking

We check the product design.

          ↓

5.Mould Design

We make mould design on the basis of confirmed product design, and send to customer for confirmation.

          ↓

6.Mold Tooling

We start to make mold after mold design confirmed

          ↓

7.Mold Processing

Send report to customer when the customer want it

          ↓

8.Mold Testing

Send trial samples and try-out report to customer for confirmation

          ↓

9. Mold Modification

According to customer’s feedback

          ↓

10.Balance settlement

50% by T/T after the customer approved the trial sample and mould quality.

          ↓

11.Delivery

UPS/DHL/EMS etc.

Mold Base:

LKM,HASCO,DME,etc.

Mold Cavity:

Single, Mult, Family

Molding Material:

ABS,PC,PP,PE,PA,PS,+GF,POM,PMMA,ect.

Color:

transparent, solid color according to your requests

Surface:

textured,glossy or mirror polished,printing,planting ect.

Design software:

PRO/E.Solidwork,UG.Moldflow.Autocad,etc

Mold Material:

S45C, P20, 718, 718H, 2738, 738H, NAK80, SKD61, E420, etc. (for reference only)

Mold Life:

300,000~1,000,000cyces according to your requests

Runner:

 Cold, hot runner such as YUDO.MASTER.SYNVENTIVE.etc.

Lead time to T1 sample:

 3~5 weeks

lead-time for production:

 1~2 weeks

Quality:

 ISO 9001:2008

Precision:

 0.02mm

Service:

 OEM &ODM service.
