HOT solar panel system;Portable solar system

Shanghai SunShine Portable Solar Home System

Good news! High efficiency YD-12200 Solar Energy System simples your life easily!

Small power station, suitable for home,camping and field activities.

Output voltage:5v USB+12v LED+220v AC

PV Model:             240~350w pv model can charge this system

Battery:                  lead-acid battery 200AH

Solar controller:    20A/12V

Inverter:                 modified wave inverter 150W

Multi-function box:4 pcs 12v DC light socket,2 pcs USB port for charge phones, 2 AC output sockets

Accessory:             Universal mobile phone charging cable 1pc,external LED lamp cable 1 set,mains charger cable 1 pc

Remark:                  charge time 7 hours for 240W solar panel

Weight:                   80.35 kg

Dimension:             500*280*410mm

Certificate:             CE&TUV&ISO

Warranty:               1 year for whole unit include battery.

Operating Instructions:

1. Charging: turn on the switch “power”, place the solar penal exposed to direct sunlight, insert the plug of the solar penal into the “solar” socket on the main device. When the charging indicator light is on, charging is in process. Flashing of the charging indicator light means charging is completed. Charging from other electricity source is optional.

2. Using with load: the system has three outputs and protection from overload and short circuit. The indicator light will be off in case of overload and short circuit. The light turns on when load is disconnected. Lifting overload by lowering the actual load will resume operation of the device. When batter power is low, all outputs are turned off. Timely recharging resumes operation of the device and prolongs useful life of the battery. If possible, connect the main device to solar penal permanently.

3. USB output is 5.5V/500mA, usable for digital products including mobile phones. Due to the variety of digital products, please prepare your own USB connection cables.

4. Please recharge as soon as possible when battery is dead, so as to maintain adequate power supply. Turn on “power” switch for recharging.

5. Press “test” button to check remaining power storage at any time,The Yellow LED flashes means the Power is running low or has run out.

6. Turn off “power” switch after use.

7. AC usage Instruction: AC and DC are separately output for this machine, if you want to change to be AC Mode, please turn on “AC POWER” switch, the Green AC Indication LED will light on, AC outlet will work, then it is OK to insert AC load. Please turn off “AC POWER” switch if no need.

300W  Solar System Load Item:

4 LED lighting

1 Radio & CD/DVD player & laptop & rice cooker
1 FAN & refrigerator etc.

power less than 300w are all ok.

About OEM&ODM:

Quality Control:
Our production management strictly according to ISO9001 standard. From material purchasing to packing , we test in every steps in order to make sure our products are qualified.
1. Our solar controller 100% tested by computer before shipment.
2. All the solar power systems are on trial-operation before shipment.

Package:

carton/wooden case.

Warmly welcome your enquiry !

Honest Is The Best Policy,We do quality &technology business.
