GR300 Motor Grader,GR300 Motor Grader,GR300 Motor Grader
Negotiable
MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
China
Brand Name:
XCMG
Model Number:
GR300
Payment & Shipping
Payment Methods:
Port of Shipment:
qingdao/shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
GR135 Motor Grader,GR135 Motor Grader,GR135 Motor GraderNegotiableMOQ: 1 Set -
XCMG GR135 Motor GraderNegotiableMOQ: 1 Unit
-
300HP XCMG Motor Grader GR300NegotiableMOQ: 1 Set
-
XCMG Motor Grader GR165 / GR180 / GR215NegotiableMOQ: 1 Set
-
XCMG GR165 Motor Grader 165HP Grader With Origional American Engine and ZF TransmissionNegotiableMOQ: 1 Set
Place of Origin
China
Brand Name
XCMG
Model Number
GR300
Specifications
GR300 motor grader1,excellent power systerm
2,reliable quality
3,advanced technology
4,long woking life
GR300 motor grader
GR300 motor grader
Basic specification | |
|---|---|
| Engine model | QSL9 |
| Rated power/speed | 224kW/2100rpm |
| Dimension(LxWxH) | 10500×3100×3550mm |
| Operating weight(Standard) | 26000kg |
Performance specification | |
| Travelling speed ,forward | 5,8,11,19,23,40 km/h |
| Travelling speed ,reverse | 5,11,23 km/h |
| Tractive force(f=0.75) | 140KN |
| Max. gradeability | 30% |
| Tire inflation pressure | 350 kPa |
| Working hydraulic pressure | 16 MPa |
| Transmission pressure | 1.3~1.8MPa |
Operating specification | |
| Max. steering angle of front wheels | ±50° |
| Max. lean angle of front wheels | ±17° |
| Max. oscillation angle of front axle | ±15° |
| Max. oscillation angle of balance box | 15 |
| Frame articulation angle | ±27° |
| Min. turning radius using articulation | 8.0m |
| Biade | |
| Maximum lift above ground | 450mm |
| Maximum depth of cutting | 500mm |
| Maximum blade position angle | 90° |
| Blade cutting angle | 28°—70° |
| Circle reversing rotation | 360° |
| Moldboard width X height | 4920×787mm |
