Home > Manufacturing & Processing Machinery > Engineering & Construction Machinery > Grader > XCMG GR165 Motor Grader 165HP Grader With Origional American Engine and ZF Transmission
XCMG GR165 Motor Grader 165HP Grader With Origional American Engine and ZF Transmission
Negotiable
MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
New
Forward Speed(km/h):
38
Reverse Speed(km/h):
23
Payment & Shipping
Payment Methods:
Port of Shipment:
China port
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
XCMG GR180 Motor Grader for SaleNegotiableMOQ: 1 Set -
190hp Motor Grader GR180 Original and Great EngineNegotiableMOQ: 1 Set
-
XCMG Motor Grader GR165 for SaleNegotiableMOQ: 1 Set
-
XCMG Motor Grader GR135NegotiableMOQ: 1 Set
-
XCMG Motor Grader GR215 With Engine CTAA8.3 160kwNegotiableMOQ: 1 Set
Condition
New
Forward Speed(km/h)
38
Reverse Speed(km/h)
23
Place of Origin
Jiangsu, China
Brand Name
XCMG
Model Number
GR165
Weight
15000 kgs
Dimension(L*W*H)
8900mm*2625mm*3470mm
Basic specification | |
|---|---|
| Engine model | D6114 |
| Rated power/speed | 125kW/2300rpm |
| Dimension(LxWxH) | 8900×2625×3470mm |
| Operating weight(Standard) | 15000kg |
Performance specification | |
| Travelling speed ,forward | 5,8,11,19,23,38 km/h |
| Travelling speed ,reverse | 5,11,23 km/h |
| Tractive force(f=0.75) | 77KN |
| Max. gradeability | 20% |
| Tire inflation pressure | 260 kPa |
| Working hydraulic pressure | 16 MPa |
| Transmission pressure | 1.3~1.8MPa |
Operating specification | |
| Max. steering angle of front wheels | ±50° |
| Max. lean angle of front wheels | ±17° |
| Max. oscillation angle of front axle | ±15° |
| Max. oscillation angle of balance box | 15 |
| Frame articulation angle | ±27° |
| Min. turning radius using articulation | 7.3m |
| Biade | |
| Maximum lift above ground | 450mm |
| Maximum depth of cutting | 500mm |
| Maximum blade position angle | 90° |
| Blade cutting angle | 28°—70° |
| Circle reversing rotation | 360° |
| Moldboard width X height | 3965×610mm |
