Help CenterMotor Grader GR180
Related Products
Specifications
1.motor grader.New appearance design.2.Tractive force(f=0.75) 79KN
3.Engine model 6CTAA8.3 D6114.
4.Maximum depth of cutting
motor grader
1.New appearance design.
2.The articulation frame is adopted and matched with the steering of the front wheel, With small turning radius,maneuvering and flexible.
3.The electro-hydraulic controls the power shift gearbox,with 6ahead gears and 3 back gears.
4.The international matching hydraulic parts are adopted,with reliable operation.
5.The motions of the blade are fully hydraulically controlled.
6.The rear axle is the three-section driving axle which is provided with the NO-SPIN self-locking differential mechanism.
7.The manipulation table and seats are adjustable. The arrangement of the manipulation handle and instruments are reasonable,with convenient application,and the comfort of driving is improved .
8.The cab is grand and nice,with wide eyeshot and good sealing .
9.The front bulldozing plate, rear scarification device,front scarification harrow and automatic leveling device can be added .
Basic specification | |
| Engine model | 6CTAA8.3 D6114 |
| Rated power/speed | 138kW/2200 140kW/2300rpm |
| Dimension(LxWxH) | 8900×2625×3470mm |
| Operating weight(Standard) | 15400kg |
Performance specification | |
| Travelling speed ,forward | 5,8,11,19,23,38 km/h |
| Travelling speed ,reverse | 5,11,23 km/h |
| Tractive force(f=0.75) | 79KN |
| Max. gradeability | 20% |
| Tire inflation pressure | 260 kPa |
| Working hydraulic pressure | 16 MPa |
| Transmission pressure | 1.3~1.8MPa |
Operating specification | |
| Max. steering angle of front wheels | ±50° |
| Max. lean angle of front wheels | ±17° |
| Max. oscillation angle of front axle | ±15° |
| Max. oscillation angle of balance box | 15 |
| Frame articulation angle | ±27° |
| Min. turning radius using articulation | 7.3m |
| Biade | |
| Maximum lift above ground | 450mm |
| Maximum depth of cutting | 500mm |
| Maximum blade position angle | 90° |
| Blade cutting angle | 28°—70° |
| Circle reversing rotation | 360° |
| Moldboard width X height | 3965×610mm |
We have all kinds of products : like GR100, GR135, GR165, GR200,GR215,GR300,GR500 and so on
