XR160 rotary drilling rig

No.

Name

Unit

Data

1

Max. drilling diameter

mm

Æ1600

2

Max. drilling depth

m

54(5parts), 42(4parts)

3

Admit safety drilling extent (arrive rotate center)

mm

3800∼4600

4

Working condition dimension

mm

8260×3940×18260

5

Transportation condition dimension

mm

13900×2940×3380

6

Overall drilling weight

T

56

7

Engine

Model

DCEC 6CTA8.3-C240

Rated power / turning speed

kW

178  /2200r/min

Max. output torque

N.m

1028 /1500r/min

8

Hydraulic system

Main pump Max. pull-down piston push

Mpa

30

Auxiliary pump max. pull-down piston push

Mpa

28

9

Rotary drive

Max. torque

kN.m

160

Max. speed

rpm

6∼26

 10

Pull-down cylinder

Max. pull-down piston push

kN

160

Max. pull-down piston push

kN

180

Max. pull-down piston stroke

mm

5000

11

Main

winch

Max. pull-down piston push

kN

160

Max. pull-down speed

m/min

70

Iron line dia.

mm

28

12

Auxiliary

winch

Max. pull-down piston push

kN

80

Max. pull-down speed

m/min

70

Iron line dia.

mm

22

13

Mast

Left/right rake

°

8 / 8

Forwards rake

°

5

Backwards rake

°

15

14

Turning platform

Turning angle

°

360

15

Walk

Overall drilling work speed

Km/h

1.5

Overall drilling Max. grade ability

%

40

16

Track

Track width

mm

600

Distance between tracksMin. Max.

mm

2340∼3340

Distance between two wheel center

mm

4240
