Specifications
KaiFan Light-duty S Series (DONGFENG) Road Wrecker1. Rated lifting weight: 4.075t
2. Max. Speed: 100km/h
KaiFan Light-duty S Series (DONGFENG) Road Wrecker
1. Working Range
KFM5074TQZ Road wrecker is used for safety salvage of vehicles subject to city road, suburb way, highway, airport and bridge road. It is suitable for medium and small-sized cargos, cars and other special vehicles, which are allowed within the technical parameters of this kind
2. Main Parameter
Items |
Unit |
Value |
|
|
Boom structure |
Rated lifting weight |
kg |
4260 |
Lifting weight of original place |
kg |
6000 |
|
Max. Lifting weight of full extension boom |
kg |
3000 |
|
Rated towing weight |
kg |
14000 |
|
Max. Designed towing weight |
kg |
25000 |
|
Effective length of boom |
mm |
2848 |
|
Extension traveling of boom |
mm |
1300 |
|
Folding angle of boom |
° |
90 |
|
|
Under lift Structure |
Max. Rated hanging weight |
kg |
6000 |
The height from hook to the ground |
mm |
4847 |
|
Extension traveling of lifting boom |
mm |
1840 |
|
Numbers of winch |
piece |
2 |
|
Rated pulling power of winch |
kg |
5000 |
|
Min. Speed of steel cable |
m/min |
7 |
|
Diameter of steel cable |
mm |
14 |
|
Length of steel cable |
m |
30 |
|
Rotation angle |
° |
37 |
|
|
Vehicle Parameters |
External dimension |
mm |
8061×2470×3000 |
Chassis model |
|
DFL1140B |
|
Drive |
|
4×2 |
|
Axle base |
mm |
5000 |
|
The whole weight of empty load |
kg |
9545 |
|
Load of front axle of empty load |
kg |
4405 |
|
Load of rear axle of empty load |
kg |
5140 |
|
The whole weight of full load |
kg |
14000 |
|
Load of front axle of full load |
kg |
5000 |
|
Load of rear axle of full load |
kg |
9000 |
|
Wheel base (front/rear axle) |
mm |
1880/1800 |
|
Front suspension |
mm |
1430 |
|
Rear suspension |
mm |
1046 |
|
Min. Turning diameter |
m |
≤19 |
|
Max. Grade ability |
% |
≥30 |
|
Max. Speed |
km/h |
90 |
|
Approach angle |
º |
20 |
|
Departure angle |
º |
18 |
|
Min. Ground clearance |
mm |
240 |
|
Engine model |
- |
ISDe185 30 |
|
Engine emission |
L |
6.7 |
|
Rated power |
kw/r/min |
136/2500 |
|
Max. Torque |
n·m/r/min |
700/1200~1700 |
|
Fuel type |
|
Diesel |
|
Tire size |
|
9.00-20 |
|
Persons |
|
3 |
|
Optional Engine |
Engine model |
|
ISDe180 30 |
Rated power |
kw |
132 |
|
Engine emission |
ml |
4500 |
|
Engine model |
|
ISDe210 30 |
|
Rated power |
kw |
155 |
|
Engine emission |
ml |
6700 |
|
