Home > Office Supplies > Presentation & Bulletin Board > Whiteboard > IR Touch Board Interactive Whiteboard With Aluminium Honeycomb Board
IR Touch Board Interactive Whiteboard With Aluminium Honeycomb Board
Negotiable
MOQ: 5 Pieces (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Whiteboard Type:
Interactive Whiteboard
Folded:
No
Brand Name:
Donview
Payment & Shipping
Payment Methods:
Port of Shipment:
shenzhen
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Trusted Brand Here, Price Best Interactive Active Board Donview 86'' Electronic WhiteboardNegotiableMOQ: 5 Pieces -
88 Inch Interactive IR Smart BoardUS$ 100 - 450MOQ: 1 Unit
-
Smart Board DB-85IND Multi Touch Active White BoardUS$ 100 - 450MOQ: 1 Unit
-
Smart Board DB-96IWS Interactive WhiteboardUS$ 100 - 450MOQ: 1 Unit
-
Easy Eraser Electronic Board DB-85IND Interactive DisplayUS$ 100 - 450MOQ: 1 Unit
Whiteboard Type
Interactive Whiteboard
Folded
No
Brand Name
Donview
Model Number
DB-98INS-Y01
Place of Origin
China
| technology and specification | |
| Type | DB-98INS-Y01 |
| Technology | Infrared induction technology |
| Board size(diagonal line) | 98'' |
| Board size(wide x high) (mm) |
1988X1496 |
| Induction size (diagonal line) |
92'' |
| Induction size(wide x high)(mm) | 1880X1388 |
| Effective projection size (diagonal line ) |
88.4'' |
| Effective projection size ( wide x high)(mm) |
1802X1340 |
| Screen Ratio | 4:3 |
| Board material | Aluminium honeycomb board |
| Resolution | 4096*4096 |
| Packing size of outside (wide x high x thickness(mm) |
2140X1665X105 |
| Whiteboard weight(kg) | 26.5 |
| Shipping weight (kg) | 50 |
| Writing | Touch operation, do not need special pen can also writing,you used the fingers and pen, pointer can realize writing and operation computer interface |
| Specific function | 1.The white frame is very thin, it’s only 40mm, make writing size bigger |
| 2.The unique radian design of edge horn, effectively reduce the blind area, expanded the actual induction area | |
| 3.Four point to location, it can write normal with projection picture of rectangle and trapezoidal | |
| 4.Without the software for the whiteboard hardware, can be compatible directly with the WINDOWS7 and to own gesture recognition function with WINDOWS7 directly, including to easy enlarge and reduce the picture, to rotate the picture with the two finger | |
| 5.First to create the serial bus technology of PCB, easy to use, easy to install, convenient to maintenance | |
| 6.The frame is the contracted and easy of aluminum alloy wire drawing oxidation, not only guarantee the beauty of products but also effective protect the PCB | |
| 7.High location, the quick speed of sample rate, the smart gesture to distinguish | |
| 8.No pollution, no electromagnetic radiation, no consumables | |
| 9.With the shortcut key to use, let the area of projection become the maximize | |
| Cursor speed | Not less than 180 dot/s |
| Board face material | High abrasion resistance, don’t care to be out of shape, use the new inventive patent to adapt the infrared touching equipment, it can be correct recognition by itself, if the whiteboard become to inset and change the shape, it doesn’t effect to write normal. |
| The way of connecting computer | USB/further distance signal propagation with wireless (the maximal length of USB: 20m). |
| Consumption current | ≤70mA(USB supply) |
| Positioning | ≤0.1mm |
| Transmission rate | 12M/S |
| Viewing angle | The right and left is 170 degree, up and down is 160 degree |
| The objects size of feeling | The diameter is 0.6cm, can reach the littler diameter which is 0.2cm |
| The operating system | WINXP,Windows vista ,WIN7 |
| Power consumption | <0.5W |
| Working temperature | -20°C to 60°C |
| Working humidity | 10-90% / 20-93%(40°C) |
| Storage temperature | -40° to 70° |
| Working time | Up 100 thousands hours |
| Warranty service | Guarantee 3 years for the board body , 1 years for the accessories and freely upgraded for ever for the software |
| Products certificates | Get the certificates of C-Tick,CE,ROHS and FCC,enterprise product standard certificate, the ministry of education teaching instrument research institute inspection report, environmental type II environmental authentication |
IF you have any question .please let me know .we will try our best to service for
you .thank you !
