JR20-160 Series Thermal Overload Relay From China

JR20-160 Series Thermal Overload Relay From China thumbnail-1
JR20-160 Series Thermal Overload Relay From China photo-1
US$ 1 - 100 MOQ: 100 Pieces
Key Specifications
Get Latest Price
Place of Origin:
Zhejiang, China
Brand Name:
GWIEC
Model Number:
GK JR20
Contact Supplier Request Quote Chat Now
Yueqing Geenwich Imp And Exp Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Ningbo
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Zhejiang, China
Brand Name GWIEC
Model Number GK JR20

JR20-160 series thermal overload relay from china

Specifications



JR20 series thermal relay is suitable for the power system of AC 50/60Hz, main circuit rated voltage up to 660V, current up to 630A, used as protecting AC three-phase motor against overload and phase losing, and forming electromagnetic with starter CJ20 series AC contactor. It has functions of phase-losing protection temperature compensation, trip indication. It can manually and automatically get back.

 JR20-160 series thermal overload relay from china



Type
 Thermal component Rated or scale of rated current Suitable contactor
JR20-10
 1R
 0.1-0.13-0.15
CJ20-10
 2R
 0.15-0.19-0.23
 3R
 0.23-0.29-0.35
 4R
 0.35-0.44-0.53
 5R
0.53-0.67-0.8
 6R
0.8-1-1.2
 7R
 1.2-1.5-1.8
 8R
 1.8-2.2-2.6
 9R
  2.6-3.2-3.8
 10R
 3.2-4-4.8
 11R
4-5-6
 12R
5-6-7
 13R
 6-7.2-8.4
 14R
 7.2-8.6-10
 15R
 8.6-10-11.6
JR20-16
 1S
3.6-4.5-5.4
CJ20-16
 2S
5.4-6.7-8
 3S
8-10-12
 4S
10-12-14
 5S
12-15-16
 6S
14-16-18
JR20-25
 1T
 7.8-9.7-11.6
CJ20-25
 2T
16-14.3-17
 3T
17-21-25
 4T
21-5-29
JR20-63
 1U
16-20-24
CJ20-63
 2U
24-30-36
 3U
32-40-47
 4U
40-47-55
 5U
47-55-62
 6U
55-63-71
JR20-160
 1W
30-40-47
CJ20-160
 2W
 47-55-63
 3W
 63-74-84
 4W
 74-86-98
 5W
 85-100-115
 6W
 100-115-130
 7W
 115-132-150
 8W
 130-150-170
 9W
 144-160-176
JR20-250
 1X
 130-160-195
CJ20-250
 2X
 167-200-250
JR20-400
 1Y
 200-250-300
CJ20-400
 2Y
 267-335-400
JR20-630
 1Z
 320-400-480
CJ20-630
 2Z
 420-525-630





 JR20-160 series thermal overload relay from china

JR20-160 series thermal overload relay from china



 JR20-160 series thermal overload relay from china
