500W Modified Sine Wave Power Inverter 48V

Name: 500W Modified Sine Wave Power Inverter 48V
Brand: GWIEC
SKU: 112260877
Availability: InStock

Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)

Key Specifications

Place of Origin:

Zhejiang, China

Brand Name:

GWIEC

Model Number:

GIE500

Yueqing Geenwich Imp And Exp Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Ningbo

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Zhejiang, China

Brand Name GWIEC

Model Number GIE500

Specification Normal

Application Home

Output Voltage (V) 100/110/120/220/230/240VAC

Load Power (W) 500VA

Solar Power (W) 1000W

Specifications

500W 48V Modified sine wave inverter
1).For solar system
2).One year warranty
3).CE EMC LVD ROHS Emark

500W Modified sine wave inverter

OUTPUT	AC POWER	100/110/120/220/230/240VAC
	RATED POWER	500w
	SURGE POWER	1000w
	WAVEFORM	MODIFLED SINE WAVE
	FREQUENCY(Hz)	55±2 60±2 50±2
	AC REGULATION	low & high 5%
	USB CHARGER	NO
	LED INDICATOR	LED DISPLAY POWER & FAIL STATUS
INPUT	NO LOAD CURRENT DRAW	<0.4A
	DC VOLTAGE	48VDC
	VOLTAGE RANGE	38.8 - 64VDC
	FUSE	20A*2

PROTECTION	BATTERY LOW SHUTDOWN	38.8 - 41.2VDC
	OVER TEMPERATURE	70°C
	OUTPUT SHORT	SHUT OFF OUTPUT VOLTAGE,RE-POWER ON TO RECOVER
	OVER LOAD	750W
	OVER VOLTAGE	60 - 64VDC
OTHER	DIMENSION	24011063MM
	PACKING	CARTON:6036.530CM 14PCS/CTN
	COOLING	NORMAL
	SOCKET	INCIDENTAL A OMNIPOTENCE SOCKET
ADDITION	NET WEIGHT(KG)	1.2KG
	gross weight	22.5KG
