LE1-D/QCX2 9~18A Series Magnetic Force Starter
APPLICATION
QCX2(LE1-D) series magnetic starter is mainly applied to circuit of AC 50/60HZ.voltage up to 660V for far distance making and breaking circult and frequently starting and controlling motor it has the reatures of small volume light weight,low power consumption,high efficiency,safe and reliable performance ect.
SPECIFICATIONS
Product mode No.and specificatiol |
LE1-D09 and 12 |
Double in sulated,protected toIP429(3) or,F659(4) |
|||||||||
Enclosure |
LE1-D18 and 25 |
Double in sulated,protected toIP427(3) or,F557(4) |
|||||||||
LE1-D32 and 95 |
Metal,IP55 to 559 |
||||||||||
Control(2 push buttons moufited on enclosure cover) |
LE1-D19 and 95 |
1 Green start button ’1’,1Red stop/Teset buttion "O" |
|||||||||
Connections |
LE1-D09 and 95 |
Electricol power and control recircuit connections |
|||||||||
Standard control circuit voltages | |||||||||||
Volts |
24 |
42 |
48 |
110 |
220/230 |
230 |
240 |
380/400 |
400 |
415 |
440 |
50/60Hz |
B7 |
D7 |
E7 |
F7 |
M7 |
P7 |
U7 |
Q7 |
V7 |
N7 |
R7 |
