China Time Go best-selling oil tank semitrailer

Main Dimensions

Tank Body

Shape

Optional(Round or Suare)

Dimension

12000mm*2490mm*3990mm(Exact size depend on the final design)

Tare Weight

About 8000Kg-12800Kg

Total Volume(m3)

25m3-60m3

Tanker Body Material

5mm or 6mm /Q235 carbon steel of Aluminum alloy

End Plate

5mm or 6mm/Q235 carbon steel of Aluminum alloy

Manhole Cover

Carbon steel or Aluminum alloy API manhole cover ,500mm

Bottom Volume

Aluminum API Pneumatic Bottom Valve

Discharging Valve

Diameter is 3 or 4 inch

Compartments

Optional

Discharging Pipe

4” rubber hose,2 pcs,6m/each

Cat Walk

With (Common model or special design)

Chassis

Main Beams

Welding design or special design I beam ,connected by bolts and nuts Q345 carbon steel material

Axle

2 or 3 axles, BPW/FUWA/HUAJING brand

Landing Gear

JOSTD200T or China brand 28T

King Pin

JOST 2.00 OR 3.5 inch bolt-in king pin

Suspension

Mechanical suspension(Germany or American type)/air suspension

Leaf spring

90(w)mm*13(Thickness0mm*10 layer or 100mm*12mm*12/without

Pneumatic Braking System

WABCO RE 6 relay valve;Spring brake chamber;2 pieces of 45L air tanks.

Rim

9.00-22.5/8.00-20/8.5-20 China brand

Tire

12.00R22.5/315 80R22.5/11.00R20/12.00R20 Brand can be optional

ABS

Optional

Painting

Complete Chassis and blasting to clean rust,1 coat of anticorrosive prime,2 coats of final paint

Accessories

One standard tool lox

Shipping Terms

By bulk cargo ship, RORO or 40HQ container
