Specifications
Use: Truck Trailer Type: Semi-Trailer Material: Steel Certification: CE Size: 10000*2500*3970 OEM No.: 3708322800116Specifications
howo used dump truck dump truck
1.Usage:for sands
2.Axles number:3
3,Capacity:75tons
howo used dump truck dump truck
Features Of howo used dump truck dump truck
1 Tipper semi-trailer for coal, ore, building materials and other bulk scattered cargo. Tipper trailer use can be divided into two categories: one category is non-road transportation of heavy and super heavy dump trailer is mainly responsible for large-scale mining, engineering and other transport tasks, usually supporting the use of excavators. Another part of the light and medium transport highway dump trailer is mainly responsible for ordinary gravel, clay, coal and other loose cargo, usually associated with supporting the use of loaders.
2.Rollover and rear compartment using turn dump way, can effectively improve the transport of bulk handling machines scattered cargo transport efficiency.
3.frame and carriage rails are made of high quality manganese plate welded cargo box with a dustpan and rectangular two kinds. High strength, lifting power, stiffness, toughness, strong bearing capacity, permanent deformation does not occur.
4.Sophisticated technology: selection of the Netherlands Hayward cards (HYVA) hydraulic jacking cylinders, lifting, stable performance, automatic submerged arc welding stringers have made use of the axle assembly machine, precision steel spring assembly.
5.According to the different needs of our customers individually designed, or tell us your goods carried by different media, we come to you to design the corresponding models, to meet customer's individual requirements
Main specification of howo used dump truck dump truck
Main Dimensions | |
Dimension |
10500*2300*1800mm (work space ) |
Tare weight |
About 18000KGS |
Total Volume(m3) |
45m3 |
Payload |
75tons |
Side wall thickness(mm) |
4mm Q235 steel |
Bottom plate thickness(mm) |
6mm /Q235 steel |
Lifting system |
Full set of Hyva (FC214-5-07130) Hydraulic Lifting Cylinder |
Chassis | |
Main Beams |
Height:500mm, upper plate is 16mm,middle is 8mm(double+reinforcing plate),down plate is 18mm,material is Q345B steel |
Axle |
3 axles, FUWA brand 16tons per axles |
Landing Gear |
JOST (C200T)(Special for exporting type) |
King Pin |
JOST 3.5 inch bolt-in king pin (Special for exporting type) |
Suspension |
America type (Special for exporting type) |
Leaf Spring |
90(W)mm*13(Thickness)mm*10 Layer (Special for exporting type) |
Pneumatic Braking System |
WABCO RE 6 relay valve; Spring brake chamber; one piece of 45L air tanks. |
Rim |
8.00-20 China Brand |
Tire |
11.00R20 Triangle Brand |
ABS |
Without |
Painting |
Complete Chassis sand blasting to clean rust, 1 coat of anticorrosive prime, 2 coats of final paint |
Accessories |
One standard tool box |
Shipping Terms |
By Bulk Cargo or roro, the tractor truck can be choose 6*4 model . |
