Specifications
25w, most popular one, CE&ISO approved,
1.The CO2 laser machine adopts sealed off CO2 laser. The CO2 laser is the unseen infrared. The characteristic is both good direction and high energy density. When the laser sent out through guiding light joint arm and the laser beam sent by focus lens, the high temperature which produced by the focus spot can gasify the target tissue, cut, cauterize and freeze the target tissue when the laser sent without through the focus lens and the lower energy density. The instrument can also be used as irradiating physical therapy when the laser beam sent by expanding beam lens and the energy density is much lower. The guided light joint arm transmitted laser is connected with the socket of the main machine, which can be unloaded to pack & transport more convenient.
2.1 laser machine
The glass tube, which is 480mms long, consist of laser machine & filled CO2 gas; Both ends of the tube stick to mirror slice separately. It's sides are installed with electode & coolingpipe. When the laser machine electrode connects high pressure with electric current, the CO2 gas is encouraged that produces the laser and sends out from the exportation germanium lens of the laser machine.
2.2 laser articulated arm
It consists of 7 joints and a guiding light tube. There are laser reflector slices in the joints.Laser beam through focus lens outputs in the interval after reflecting for many times. The fan-out can go together with focused mirror and with all kinds of operation head- knife.
2.3 power supply part
It consists of transformer & switch power supply. The output power of laser can be adjusted with switch power supply to change the current.
2.4 Control part
It consists of control power, computer panel and control panel.
2.5 Cooling off the water circulatory system
It will produce heat when the laser machine works. The inner circulating water cools off.
The pure water exists in the tank. The water pump sends water to the laser pipes via controller and reflows to water tank.
2.6 Indication laser device
When computer controls laser, preparation( READY), will shoot the red laser which is the CO2 light road instructions.
2.7 Laser controls switch( the feet steps the switch)
The footswitch of the treatment is drop proof type, which is applicable to the laser treatment room & not suitable with the operating room.
2.8 Cooling system protection
If the circulating cooling water appears trouble, it will damage the laser, When the laser machine lacks water, or water temperature is over 45 °C, .the computer will cut off the power supply to send alarm sound and lighten on the indicator of the panel.
2.9 Cover interlock
The power will be cut with interlock for safety when the cover of the box is moved.
2.10 Light brake
It is a safety device. The light brake will be open when stepping on the foot-switch, otherwise it will be close.
3. Parameter
Color computer screen: 8 inch touch screen color,
Laser wavelength: 10600nm
Power to tissue: >25W (C.W)
Focal spot diameter: <0.5mm
operation mode: CWsingleRepeat pulseUltra pulse
articulated arm: 7-joint spring-balanced
Working radius: 130cm
Aiming beam Diode laser: 635nm2mW
Ultra pulse width: 0.1—2mS
pulse recurrence rate: 5-500 mS
Tissue Exposure Modes: CW Repeat pulseUltra pulse
Power supply: AC220V or 110V
L×W×H: 42×38 ×100cm
Packing L×W×H: 47*49*113cm
Gross Weight: 40kg (Net weight 30kg)
