High Voltage Fuse Link type K & T for cutout fuse

Specifications

high voltage fuse link 11kV-38kV, 1A-300A
1.Material:copper
2.according to ANSI/IEEE C37.41, C37.42 standard, IEC-282 standard



Type K & T Fuse Links ( cartridge fuse links ) for Dropout Fuse Cutout.

1).Product Description:
This fuse wires apply to the 11KV -36KV DROP OUT FUSE.

2).Standard:
according to ANSI/IEEE C37.41, C37.42 standard, IEC-282 standard.


3).Technical specification:
Rated Current: 1A-300A
Rated Voltage: 11KV-36KV
Length: 530mm-787mm



Length of fuse link can be make according to requests.
