Home > Manufacturing & Processing Machinery > Laser Equipment > Laser Cutting Machine > Double Column Cnc Machining Center VL3500
Double Column Cnc Machining Center VL3500
US$ 105,000 - 106,000
MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Place of Origin:
Shandong, China
Brand Name:
YZ CNC
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao/Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Common Rail Safety Valve Test BenchNegotiableMOQ: 1 Set -
Injector Safety Valve Test BenchNegotiableMOQ: 1 Set
-
Iniector Assembly Tool Set,and Calibration Shims Set Bosch Common Rail Diesel Injector Calibration ShimNegotiableMOQ: 1 Set
-
PS400A Nozzle Calibration TesterNegotiableMOQ: 1 Set
-
CRS100 High Quality Common Rail Pump Test Bench/fuel Pump Pressure TesterUS$ 10,000 - 20,000MOQ: 1 Piece
Condition
New
Place of Origin
Shandong, China
Brand Name
YZ CNC
Model Number
VL3500
Voltage
220V/380V
Rated Power
7.5kw
Dimension(L*W*H)
7000*1700*2700 (mm )
Weight
12000kgs
Certification
CE ISO
Warranty
1 Year
After-sales Service Provided
Engineers available to service machinery overseas
VL3500 Double Column Gantry CNC Machining Center
|
VL3500---Linear guideways |
||
Travel |
X axis |
3500mm |
|
Y axis |
900mm |
||
Z axis |
900mm |
||
Feed |
max X rapid feed |
20 m/min |
|
max Y rapid feed |
20 m/min |
||
max Z rapid feed |
18 m/min |
||
Cutting feed |
1-10m/min |
||
Torque |
X:30N.m Y:15 N.m Z:38N.m |
||
Table |
Table size |
3400*800mm |
|
Max load |
2000Kg |
||
Table surface to floor |
750 mm |
||
T slot |
5*18*100mm |
||
Spindle |
Type |
Direct Drive |
|
Speed |
12000 rpm |
||
Spindle taper |
Sk40 |
||
Main motor |
7.5 kw
|
||
Accuracy |
Accuracy (JIS) |
0.005/300mm |
|
Repeatability (JIS) |
0.003mm |
||
Other |
Weight |
12000 Kgs |
|
Size |
7000*1700*2700 (mm ) |
||
