HOTEL MANAGEMENT CONVENIENT KEY CARD HOTEL POWER SWITCH

Specifications

hotel power switch
Current: 30A
Delay time: 10 seconds or specified,
Voltage: 220V
Induction card (EM or TEMIC)

hotel power switch



hotel power switch Specification:

Type	GD-B-11
Voltage of opening lock:	220 V
Current of opening lock:	30A
Delay time	10 seconds or assigned
Extension length of dead bolt:	13mm
Static consumption	0.01w
Locking method:	by collision
Dimension:	85*85*45 mm
Surface Temp:	≤+20°C
Apply range	hotel, house and office building television network
Suitable Humidity:	0~90%(non-condensing).
Gross weight	200g
Latch bolt material:	PC





hotel power switch Main Feature:

When leaving the room, the guest take the key card away (you have to pull out cards, because you would also like to use this card to open the door when you back),Energy saving switch will cut off the power within 15 seconds automatically. It can bring direct economic benefits (electricity savings) for the hotel, to extend the life of electrical equipment, to enhance guest safety factor of electricity, to achieve energy-saving effectively for hotel. Investing least cost to reach the effect "energy-saving emission reduction" for the hotel.







In accordance with the general standard guest room s appliance configuration
Right-left bedside lamp 25~40W*2     mirror front lamp 20 W      floor lamp25-40 W
                                            TV 120 W            desk lamp 25~40W       porch light 25W
Separate Air Conditioner 1000 W       Total power:1300 W=1.3KW
According to the power calculation, if there are 100 rooms in hotel, and 0.15 USD/ kWh. If we could saved one hours for each room daily power, then the hotel could be saving electric charge each year: 1.3 kilowatts × 100 rooms × 1 hours / day × 365 days × 0.15USD / kWh = 7117.5USD.



Function and Application:

Taking down the fixed plastic shell and panel shell from the buckling position, then use the self-providing self tapping screw fix it on designated position.

  According to the manner as required (normally open or normally closed), connect the wire with the joint of panel  shell after take holding of the wire protruded from the fixed plastic shell



   That are OK after put the panel shell on the fixed plastic shell



Packing:

1 box including 100 pcs

hotel power switch product overview: Physical map:
