Specifications
4 Channels Mobile DVR1.Anti-shake,dustproof
2.used in vehicles or supermarkets
3.Multilingual menu
4.Multi-operation mode
4 channels H.264 high performance moible dvr with GPS, Wi-Fi option
Model:VR8800
H.264 compression format; SD CARD/HDD/USB flash drive; Max memory: 2TB; 4 channels Audio & Video; D1/HD1/CIF/QCIF; 1~30fps (optional); Manual record/Scheduled record/Alarm record(motion detect, video loss, video blind); IR remote(Support external IR sensor)/USB mouse; Internet interface: RJ45 Port; Cycle recording;
Main Features:
With a 3.5 inch TFT display (optional);
Works with power supply ranging from DC8V to DC36V;
Supports Manual Record, Motion Detect and scheduled Record;
Video resolution: D1/HD1/CIF/QCIF selectable for each channel; framerate: 1-25fps (PAL) or 1-30fps (NTSC) for each channel;
Supports 4 channels “Video & Audio” recording and playback simultaneously;
Video clips can be saved onto either SD card or HDD;
Supports SD card upto 32G and 2.5” Sata HDD upto 2TB;
With shell lock, user password to keep the data safe;
Power-off delay to guarantee the DVR would shut down normally to keep recorded files safe when an emergency occurs;
Can work with 4 cameras, and power 4 cameras directly;
Supports GPS (optional), WIFI (optional), and 3G (optional);
Technical Specifications:
System |
Main processor |
High performance embedded microprocessor |
Operation system |
Embedded LINUX operation system |
|
User Interface |
display |
1/4 image display |
Languages |
Multi languages, more than 15 species of languages |
|
Operation |
Operation mode |
USB mouse, control panel, IR remote control |
Video |
Frame rate |
1-25fps (PAL) or 1-30fps (NTSC) for each channel; |
Image quality |
D1/HD1/CIF/QCIF for each Channel |
|
Playback image quality |
D1/HD1/CIF/QCIF for each Channel |
|
compression format |
H.264 |
|
|
Record And Playback |
Recording mode |
manual >sensor>motion detect>timing |
Recording storage |
HDD, SD card, USB Flash drive, other movable devices |
|
Backup mode |
USB flash drive, Movable HDD, USB interface devices |
|
Port |
Video input |
4 channel |
Video output |
1 channel |
|
Audio input |
4 channel |
|
Audio output |
1 channel |
|
Alarm input |
4 channel |
|
Alarm output |
1 channel |
|
Network port |
RJ45 10M/100M |
|
PTZ control port |
1 RS485 |
|
USB port |
2* USB2.0 ports for USB mouse and movable devices |
|
Hard disk port |
1 SATA port, Support 2.5” SATA HDD, MAX capacity:2TB |
|
Other |
Power supply |
8-36V external power supply |
Power consumption |
<15W (without hard disk) |
|
Working temperature |
0°C~+55°C |
|
Working humidity |
10%-90% |
|
Air pressure |
86kpa-106kpa |
|
Dimension |
180mm (L) x 50mm (W) x 194mm (H) |
