Specifications
1. 4-ch VEHICLE DVR2. remote monitoring
3. pass word access
4. Max. support 1000GB HD
5. anti-vibration design
4-CH vehicle CCTV DVR--VR8800N
Main fetures:
1. Adopt anti-vibration design. All connectors are anti-vibration. There are 12 small cushions to protect the hard disk, all datas are safe in hard disk. It can work normally if the road is bumpily.
2. Immediately get into the "preview mode(ready to record)" once power on. Software installation do not needed.
3. Can use IR remote control, which makes operation much more convenient for user.
4. Power on/off delaying to protect hard disk and ensure all files are well saved in hark disk, they won't be lost if power went off suddenly.
5. Comopatable with any CCD OR CMOS camera.
6. can connect and power 4 cameras directly, extral powr for cameras do not needed, which will not only save you a few dollars, but also save you from the troublesome cables. 4 channels can be recorded synchronously.
7. 2.5" SATA HDD, maximum support upto 1000GB.
8. LCD will turn off automatically once DVR cover is closed, so as to save power.
9. compatible with PAL or NTSC video standard.
10. D1 resolution, NTSC:720*480/60fps; PAL: 720*576/50fps
11. adopt optimized MPEG-4 video condec, easy to realize high clear video transmission through low bandwidth.
12. RJ45 interface, realize remote monitoring.
13. mult-users managent via password
14. safe lock, pass word, special software keep data safe.
15. multiple record modes can be set on main meau for different hours: motion detection, schedule record and manual record.
16. motion detection record: DVR will automatically take video if there is moving object pass by camera.
17. schedule record: DVR will automatically take video once a pre-set time peoriod comes.
18. software upgrade online upgrade is avaliable.
19. with two USB 2.0 ports, data can backup to computer easily.
20. with a low power consumption fan to cooling down the unit.
Parameters
Model |
VR8800N(4-CH HDD DVR) |
Working Voltage |
DC 8-36 V(DC 14-36 V when power camera) |
Maximum Current |
≤2.5 A |
Output Voltage(for camera) |
DC12 V |
Power Supply |
Car battery |
Maximum Memory Capacity |
1000 GB |
CompressionFile Format |
MPEG2/MPEG4 |
Record Switch |
Continuous record or motion detect |
Record mode |
Motion detect,schedule and manual record |
Record Quality |
3 rating adjustable |
Resolution |
D1 (PAL 720*576,NTSC 720*480) |
Frame Rate |
PAL(1~50fps optional) NTSC(1~60fps optional) |
Record AV in signal |
4 CH video+2 CH audio |
File Store Mode |
Overwrite when full or stop when full |
Internet Interface |
One 10M/100M RJ45 |
Alarm output |
Can connect alarm with audio and light |
HDD Interface |
One 2.5″SATA HDD interface |
Compatible camera |
Common CMOS & CCD |
Dimension |
194mm*180mm*50mm |
Optional Functions |
Panning Table control |
