Widely Use Outdoor Access Control Biometric Fingerprint Reader System

- The device is built-in ID card sensor(optional for IC card), validate freely by Card, fingerprint and password combination,
access control is more flexible and securely.
- TCP/IP communication, network connection is simple and convenient, support Push Technology,
operate access control networking and data collection & share freely
- With multi-level validation, lock combination and anti-pass back functions.
- With tamper alarm, over-time door opening alarm, fire alarm and Hijack alarm ect alarm functions
1.Three ways to authentication and open door :Swipe card, Password,Fingerprint optiona
2.TCP/IP or RS232 or RS485 connect.
3.Support USB Host/Device
4.The Three types method to open the door:card,password,card and password.
5.Built-in non-contact card reader(125KHZ).
6.Eight auxiliary mode, open the door alarm, and so on security mode.
7. the machine can used as card reader.
8. open closed and automatically backlit mode.
9.With functions of tamper alarm and safe operation mode.
10. button with blue backlight
11.Swipe card ,password, swipe card +password , Fingerprint optiona

| Name | Fingerprint time attendance access control machine |
| Fingerprint capacity | 1000 pcs |
| Recording capacity | 10000pcs |
| Comunication mode | 1 line RS485/232 TCP/IP |
| Opening method | fingerprint or password or proximity card or Any combination |
| card type | ID/IC |
| Dimension | 326*123*13 mm |
| Recording speed : | ≤0.75 s |
| Working temperature | 0-45 °C |
| Working humidity | 20-80% |
| Language | Chinese/English |
| Reading range | 4-15cm |
| FAR | ≤0.0001% |
| FRR | ≤0.01% |
| Power supply | DC 12V |
| Screen | Blue backlit white Word |
| Connect port | TCP/IP or RS232 or RS485 |
| current: | 1A |
| FRR: | ≤1% |
Use place:
1. Industrial zones 2. Administrative buildings 3. Recreation centers 4. Amusement parks 5. Financial institutions
6. Airports 7. Bus and railway stations 8. Offices.

1 box including 100 pcs
1.Paper box inside
2.Wooden box outside
3.Delivery method follows :
4. any other way
Shanghai Gengda Electronic Technology Co., Ltd. is founded in 2009.We are a private enterprise professionally engaged in security system products in wordwide.Research,production,market and service are integrated one unit.Our categories are tripod turnstile,flap turnstile,swing turnstile,access control system,smart card,electronic lock,control board,power box,road barrier, Anti-static tester and all accessories.What a surprise,
Look forward to the future,we keep a foothold of innovation.We will bring back the best products and optimal service to our noble clients.
Company Target:Innovative products and solution,higher value,to be the full-scale one-up supplier
Management idea:Fall for all clients,creat international brand
Enterprise soul:Value comes from creation,reputation above all else
