Toplovo TL301 GPS Tracking Chip for Dogs with Shake Motor, GEO FENCE Alarm, Night Light

Name: Toplovo TL301 GPS Tracking Chip for Dogs with Shake Motor, GEO FENCE Alarm, Night Light
Brand: Toplovo
Availability: InStock

FOB Price

USD $55 - $75 / Unit

1 Unit(Min.Order)

Supply Ability 10000 Unit / Units per Month
Port Shenzhen
Payment TermsCredit Card

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Type	Other, Gps Tracker, GPS Tracking Chip for Dogs	Use	Hand Held
Screen Size	Other, no	Function	Other, GPS Tracking Chip for Dogs
Place of Origin	Guangdong, China	Brand Name	Toplovo
Model Number	TL301 GPS Tracking Chip for Dogs

Product Description

Toplovo TL301 GPS Tracking Chip for Dogs with Shake Motor, GEO FENCE Alarm, Night Light

Toplovo's Official Website:

Contact: Cherry Skype: cherry-gps

Mobile: +8613500066672

1. Introduction
Working Based on existing GSM /GPRS network and GPS satellites, this GPS tracker is a small and powerful tracking device that is developed for personal, vehicle and pet etc. Not only transmit the longitude and latitude coordinate to your cell phone by SMS, but also transmitting the longitude and latitude coordinate to the designated server by GPRS and then displaying the location by tracking software.

What's new?
3.1 Smaller size: It’s very small, and can be worn to Dog’s neck.
3.2 Longer battery life (standby time is 15days)
3.3 Position accurate will combine the GPS info and GSM base station info.
3.4 Can send a command to turn on the flashing light, it would easier for you to find your pets at night.
3.5 The device has shake motor to remind the dog doing sth.
3.6 Get instant position by calling the tracker, sending a command or clicking on the power button.
3.7 Get position by 3 ways: Search the coordinate in Google map, click the URL and see the position in cell phone directly and view the position and history in tracking software.

3. Main Features
1. Long battery 2200mAh(15 days)
2. Real-time tracking by SMS/GPRS
3. Rainproof
4. History reply in software.
5. One button Geo-fence alarm on/off
6. Night flashing light
7. Speeding alarm
8. Low Battery alarm
9. Shake Motor

4. Applications
Protect the child/elderly/disabled/pet etc.
Personnel management
Track the vehicle/ equipment etc.
Provide peace-of-mind for businessmen

5. Specification
Dimension: 75.8*39.8*25mm
Network: GSM/GPRS
Band: 900/1800Mhz or 850/900/1800/1900Mhz
GPS chip: MTK chip
GPS sensitivity:-159dBm
GPS accuracy: 5-20m
Cold start: 38sec.
Warm start: 36sec.
Hot start: 1sec.
Battery: Chargeable 3.7V 2200mAh battery

Switch on the unit outdoors. Three LEDs will be bright at the same time during the tracker starting. In 10 to 30seconds, the unit will begin to work and indicators will blink as the following:

7. Get the position by calling the tracker

You can use the authorized numbers to call the tracker SIM number for at least 2 seconds, then hang up the call before the tracker hangs up or receives it. The tracker will reply a position SMS with latitude and longitude in it. You can put the coordinate into Google map and search for the position. The tracker will not reply the SMS If you did not hang up the call before the tracker hangs up or receives it.

The tracker will reply to any incoming call number if you have not set the authorized numbers yet. Once you have set the authorized number, the tracker will reply SMS to the authorized numbers only.

8. Set the authorized number

Send SMS“123456A1,phone number” to set the first SOS number.

Send SMS“123456A2,phone number” to set the second SOS number.

Send SMS“123456A3,phone number” to set the third SOS number.

Send SMS“123456A4,phone number” to set the CALL1 number.

Send SMS“123456A5,phone number” to set the CALL2 number.

Note: 123456 is the default password. ‘A’ and the comma must be English in capital and make sure there is no space in the command. Phone number must include the country code

E.g. send SMS “123456A1,+8613812345678” to set +8613812345678 as the first number. +86 is the country code of China. Please do not use 00 instead of +.

It doesn’t mean that you have to set all of the five authorized numbers, but at least one authorized number. Then the device will only accept the SMS commands from this particular authorized numbers. Besides, you can set one phone number as A1 to A5.

9. Get position by sending SMS command.

Send SMS “123456F” to the device and it will reply its position as well as the location URL by SMS. Only the authorized number can get the reply.

Note: F must be English in capital.

E.g. send “123456F” to the unit. It will reply its position.

The first preset number will take priority over the second one and the third one. If the tracker fails to connect to the first number, it will switch to the second one, In case the second number fail to be connected too, the system will connect to the third number, This will go on and on until one of the telephones picks up, then two-way communication starts.

10. Get instant position via THREE ways
10.1 Get instant position by calling the tracker
You can use the authorized numbers to call the tracker SIM number for at least 2 seconds, and then hang up the call before the tracker hangs up or receives it. The tracker will reply a Google position URL SMS. You can click on this URL to see the position. The tracker will not reply the SMS If you did not hang up the call before the tracker hangs up or receives it.
Note: The tracker will reply to any incoming call number if you have not set the authorized numbers yet. Once you have set the authorized number, the tracker will reply SMS to the authorized numbers only.

10.2 Get instant position by pressing ON/OFF button
You can get a Google position URL SMS by pressing the power button (around one second) till the LED flashing fast.
Note: This link SMS will just be sent to the A1, A2 and A3 authorized numbers.

10.3 Get instant position by sending SMS command
Send “123456F” to the unit. It will reply its position.

11. Low battery alert

Send SMS “123456(N 0/N1),xx” to set the low-battery alert.

Note: N must be English in capital, N0 means turn off this function; N1 means turn on this function. xx should be <45 and must be 2 numbers.

E.g. send“123456N1,30” to the tracker means when the battery is lower then 30%,it will send an alert to the authorized number. Send“123456N0,30” to the tracker means turn off the low battery alert function.

12. Auto-track function
Send SMS “123456M0/M1, xxxS/M/H” to the unit, the tracker will reply the location URL messages to A5 according to the time interval. If the device has been connected to the server, the reply data will be sent to the server only, which means the server has the priority.

13. GPRS setting
Send SMS “123456B” to get the IMEI number of the unit.
Note: B must be capital.
E.g. send SMS “123456B”

Note: Before you execute the following GPRS connection, please submit the IMEI # to the manufacturer to register the IMEI #.

In order to use GPRS function, the user needs to set IP, Port and APN (Access Point Name) by sending SMS commands. Make sure that the SIM card in the tracker has the GPRS function activated.
Send SMS “123456C$$$$,IP:Port” to set the APN, IP and port.
Note: C must be capital. Please get APN from your local GSM operators and the APN is case sensitive. Users do not need to input the server's IP & Port if you use the manufacturer's server.
E.g. send SMS “123456CCMNET”.CMNET is the APN of China Mobile, and it will connect the manufacturer's server as a default mode.
Note: The APN should be in wap mode.

Send SMS “123456O&&&&, @@@@” to set the username and password for APN.
Note: &&&& is the username and @@@@ is the password. O must be capital. If the GSM provider doesn’t create a username and password for the APN, you can ignore this command.
E.g. send SMS “123456Owap, wap”.
Note: The username and password should be in wap mode.

Send SMS “123456D” to turn on GPRS connection
Note: D must be capital.
E.g. send SMS “123456D”

Send SMS “123456E” to turn off GPRS connection
Note: E must be capital.

Cautions:

Please comply with the instructions to extend the unit life:

1. Keep the unit dry. Any liquid, i.e. rain, moisture, may destroy or damage the inside circuitry.

2. Don’t use & store the unit in dusty places.

3. Don’t put the unit in overheated or overcooled places.

4. Handle carefully. Don’t vibrate or shake it violently.

5. Clear the unit with a piece of dry cloth. Don’t clean in chemicals, detergent.

6. Don’t paint the unit, this may cause some foreign materials left in between the parts.

7. Don’t disassemble or refit the unit.
