14 Ton Capacity Forklift

14 Ton Capacity Forklift thumbnail-1
14 Ton Capacity Forklift photo-1
US$ 1 - 100,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Place of Origin:
Shandong, China
Brand Name:
SHANTUI
Contact Supplier Request Quote Chat Now
Shandong Volin Heavy Machinery Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao/Shanghai/Tianjin
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Place of Origin Shandong, China
Brand Name SHANTUI
Model Number SF140
Type Powered Pallet Truck
Power Souce Diesel Engine
Rated Loading Capacity 14000kg
Max. Lifting Height 6000mm
Min. Lifting Height 3500mm
Fork Length 2400mm
Fork Width 200mm
Overall Dimensions 7850x2560x3750mm
Certification ISO9001/ISO14001/CE
After-sales Service Provided Engineers available to service machinery overseas
Product Description

Product Advantages

Shantui14.0Ton diesel forklift (SF140)equipment with CUMMINS engine, German ZF brand transmission,Kessler  Wet brake driving axle,USA Parker hydraulic Syetem,cabin and Air conditioner,electric control side shift and fork posioner.It is widely used to handing all kinds of goods,such as pallet,steel,brick etc.Shantui has cooperated with KOMATSU more than 30 years,all the product was made under KOMATSU standard.





Engine
Model
Cummins QSB6.7

Rated Output
142/2300
Kw/rpm
Rated Torque
930/1500
N·m/rpm
No.of cylinder
6

Bore×stroke
107×124
mm
Displacement
6.7
L


Dimensions
Lifting Height
3500
mm
LxWxH(With/Without Fork)
7850(5450)x2560x3750
mm
Turning radius
5000
mm
Mast tilt angle(F/R)
6/10
Degree


Performance
Travel speed(full load/no load)
28/30
Km/h
Lift speed (with /without) load
350/380
mm/sec
Max.gradeability
28
%
Self weight
22000
Kg


Wheel&tires
Front
12.00-20-20PR

Rear
12.00-20-20PR

Wheelbase
3750
mm
Min.ground clearance(mast)
210
mm
Detailed Images

Comfortable Drving Room.

Suspension Seat,joystick operating bar,Cabin and AC ,Radio and Fire extingusher.

Easy Operate.

Hydraulic assisted steering wheel,electric control bar

Front Working Lamp.

Shantui 16Ton forklift equipment with high quality front working lamp which makes the machine working at night.

Ergonomics Design.

When Design the forklift,Shantui pay attention to the ergonomics.Such like Anti-Slip Pedal,Wide view mast.

Long forks with multiple Function.

Using A 2.4Meter Long forklift,can be adjusted by posioner and side shifter.

Easy control system.

All the control bar were easy find,makes the operator easy to control.

Working Performance
Packing & Delivery
Shipping
By Lorry,From the factory to port ,by Ro-Ro shipment when shipping.
Packing
Nude Packing,forks disassembled.
No. of packets
Forklift    1  set            Fork     2   pcs.                Tool box   1 Set
Measurement
55CBM
Weight
22000KGS
Our Service

Pre-Sales Service

* Inquiry and consulting support.

* Sample testing support.

* View our Factory.

After-Sales Service

* Training how to instal the machine, training how to use the machine.

* Engineers available to service machinery overseas.
