3T SHANTUI Electric Forklift

3T SHANTUI Electric Forklift thumbnail-1
3T SHANTUI Electric Forklift thumbnail-2
3T SHANTUI Electric Forklift thumbnail-3
3T SHANTUI Electric Forklift thumbnail-4
3T SHANTUI Electric Forklift thumbnail-5
3T SHANTUI Electric Forklift thumbnail-6
3T SHANTUI Electric Forklift photo-1
3T SHANTUI Electric Forklift photo-2
3T SHANTUI Electric Forklift photo-3
3T SHANTUI Electric Forklift photo-4
3T SHANTUI Electric Forklift photo-5
3T SHANTUI Electric Forklift photo-6
US$ 5,000 - 22,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Place of Origin:
Shandong, China
Brand Name:
SHANTUI
Contact Supplier Request Quote Chat Now
Shandong Volin Heavy Machinery Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao/Shanghai/Tianjin
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Place of Origin Shandong, China
Brand Name SHANTUI
Model Number SF30S
Type Other, Powered Pallet Truck, SF30S
Power Souce AC Motor
Rated Loading Capacity 3000kg
Max. Lifting Height 6000mm
Min. Lifting Height 3000mm
Fork Length 1070mm
Fork Width 122mm
Overall Dimensions 3545x1260x2135mm
Certification ISO9001/ISO14001/CE
After-sales Service Provided Engineers available to service machinery overseas
Product Description

Product Advantages

Shantui 3.0Ton electric forklift (SF30S)equipment Zapi Controller,Full Ac Driving & Lifting Motor, LED display instrument,automatic transmission, hydraulic assisted steering valve,Large-capacity Battery for long working hours,Advanced high efficiency controlling system,Low Heat & Noise.It is widely used to handing all kinds of goods,such as pallet,steel,brick etc.Shantui has cooperated with KOMATSU more than 30 years,all the product was made under KOMATSU standard.




Battery & Charger
Battery Voltage/Capacity
48V/600Ah
V/Ah
Battery Charger
380~440V/50Hz
V/Hz
Battery Weight
1120
Kgs
Driving Motor
11.75
KW
Lifting Motor
10
KW


Dimensions
Lifting Height
3000
mm
LxWxH(With/Without Fork)
3545(2475)x1260x2135
mm
Turning radius
2135
mm
Mast tilt angle(F/R)
6/12
Degree


Performance
Travel speed(full load/no load)
17/15
Km/h
Lift speed (with /without) load
260
mm/sec
Max.gradeability
13
%
Self weight
4850
Kg


Wheel&tires
Front
28×9-15-14PR

Rear
18X7-8-14PR

Wheelbase
1585
mm
Min.ground clearance(mast) with load/without load
105/120
mm
Detailed Images

Large capacity Battery.

ZiBO Torch Brand High quality battery.
Large capacity,long working hours.


Automatic Transmission.

Electric control standard,the user canbe operate the lever by finger.

Safety Button.

In case any danger occurs,just press the button,the machine will be stopped immedicately.

High Quality Controller

Shantui electric forklift adopts world-class Curtis Or Zapi Controller to ensure excellent performance.

Full AC Motor

Excellent Driving & Lifting AC motor,Free Of Maintenance.

LCD Instrument

Interface friendly interactive multi-function Liquid Crystal Display With Password Setting Function.

Working Performance
Packing & Delivery
Shipping
By Container,2 sets per 20 feet container,5 sets per 40 feet container.
Packing
Nude Packing,Four tires fixed
No. of packets
Forklift    1  set            Fork     2   pcs.     Tool box   1 Set                               Battery Charger 1Set
Measurement
9.5CBM
Weight
4850KGS
Our Service

Pre-Sales Service

* Inquiry and consulting support.

* Sample testing support.

* View our Factory.

After-Sales Service

* Training how to instal the machine, training how to use the machine.

* Engineers available to service machinery overseas.
