Brand New Electric Forklift 3T With Paper Roll Clamp

Brand New Electric Forklift 3T With Paper Roll Clamp thumbnail-1
Brand New Electric Forklift 3T With Paper Roll Clamp photo-1
US$ 8,000 - 20,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Place of Origin:
Shandong, China
Brand Name:
SHANTUI
Contact Supplier Request Quote Chat Now
Shandong Volin Heavy Machinery Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao/Shanghai/Tianjin
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Place of Origin Shandong, China
Brand Name SHANTUI
Model Number SF30S
Type Powered Pallet Truck
Power Souce AC Motor
Rated Loading Capacity 2500kg
Max. Lifting Height 8000mm
Min. Lifting Height 3000mm
Fork Length 1070mm
Fork Width 122mm
Overall Dimensions 3445x1160x2130mm
Certification ISO9001/ISO14001/CE
After-sales Service Provided Engineers available to service machinery overseas
Product Description

Product Advantages

Shantui 3.0Ton electric forklift (SF30S)equipment Zapi Controller,Full Ac Driving & Lifting Motor, LED display instrument,automatic transmission, hydraulic assisted steering valve,Large-capacity Battery for long working hours,Advanced high efficiency controlling system,Low Heat & Noise.It is widely used to handing all kinds of goods,such as pallet,steel,brick etc.Shantui has cooperated with KOMATSU more than 30 years,all the product was made under KOMATSU standard.

General
Model
SF30S
Load capocity
3000
kg
Load center
500
mm
Power type
Battery
overall length with/without forks
3545/2470
mm
overall dementions
overall width
1295
mm
overall height
2135
mm
overall height fork lowered
2065
mm
overall height fork raised
4272
mm
max.lifting height
3000
mm
free lift height
80
mm
min.under-clearance(frame)
140
mm
front overhang
495
mm
wheel and tires
wheel base
1585
mm
rear overhang
392
mm
lateral fork adjustment(outside)
250/1090
mm
front tread
1000
mm
rear tread
980
mm
min.turning radius
2135
mm
performance
Mast tile angle
6/12
o
battery voltage/capacity
80/500
V/Ah
travel speed with/without load
15/18
Km/h
lifting speed with load
260
mm/sec
Max.gradeability
13
%
weight of battery
1331
kg
front tire
28×9-15-14PR
rear tire
18×7-8-14PR
sevice weight
4850
kg
Detailed Images

Large capacity Battery.

ZiBO Torch Brand High quality battery.
Large capacity,long working hours.


Automatic Transmission.

Electric control standard,the user canbe operate the lever by finger.

Safety Button.

In case any danger occurs,just press the button,the machine will be stopped immedicately.

High Quality Controller

Shantui electric forklift adopts world-class Curtis Or Zapi Controller to ensure excellent performance.

Full AC Motor

Excellent Driving & Lifting AC motor,Free Of Maintenance.

LCD Instrument

Interface friendly interactive multi-function Liquid Crystal Display With Password Setting Function.

Working Performance
Packing & Delivery
Shipping
By Container,2 sets per 20 feet container,5 sets per 40 feet container.
Packing
Nude Packing,Four tires fixed
No. of packets
Forklift    1  set            Fork     2   pcs.     Tool box   1 Set                               Battery Charger 1Set
Measurement
7.0CBM
Weight
4250KGS
Our Service

Pre-Sales Service

* Inquiry and consulting support.

* Sample testing support.

* View our Factory.

After-Sales Service

* Training how to instal the machine, training how to use the machine.

* Engineers available to service machinery overseas.
