diesel fuel injection pump test bench/sand/bank PCME(displayed by LCD and digital)

Name: diesel fuel injection pump test bench/sand/bank PCME(displayed by LCD and digital)
Brand: xingzhou
Price: USD $3,000 - 4,000 / Set

FOB Price

USD $3,000 - $4,000 / Set

1 Set(Min.Order)

Supply Ability 500 Set / Sets per Month
Port qingdao shanghai guangzhou
Payment Terms:T/T D/P D/A Credit Card

Request Sample Customized Request Download Product Catalog

Contact Now

Get lowest price Inquiry Basket

Product Details

Place of Origin:	Shandong, China	Brand Name:	xingzhou	Model Number:	PCM-E
Power:	Electronic	Usage:	Auto Testing Machine

Packaging Details

packing in wooden case
fittings for delivery

Product Description

Specifications

1.Testing12-cylinders fuel pump
2.Output power 7.5kw/11kw/15kw/18.5kw/22kw
3.Displayed by LCD and digital
4.Windows XP system

PCM-E Diesel fuel injection pump test bench (ce certificate)

Functions:
1 Testing 12-cylinder fuel injection pump.
2 Measuring each cylinder delivery at any speed.
3 Checking each cylinder injection timing with static.
4 Checking the sealing injection pump body.
5 Checking the mechanical governor.
6 Checking the pneumatic governor.
7 Checking the vacuum capacity of governor.
8 Checking the pressure compensators(LDA).
9 Measuring the internal pressure of distributor pump body.
10 Testing the electromagnetic valve of distributor pump.
11 Checking transfer pump.
12 Measuring the reflux delivery of distributor pump body.

Parameters :

Output power	7.5kw,11kw.15kw.8.5kw,22kw
Power supply	3-phase 380V/50HZ,3 phase-220V/50HZ
Interaxe height	125mm
graduates	45CC,150CC
Tank volume	60L
DC supply	12/24V
Feeding fuel pressure	Low 0--0.4Mpa, High 0--4Mpa
Range of speed	+/-4000RPM
Control temperature	40+/-2°C
Filter accuracy	5u
Air pressure	-50+300Kpa
Size:	2.41.22m
Weight	870kg

1. Output power(KW): 7.5/11/15/18.5/22Optional

2 Power supply: 3-Phase)380V/50Hz (or on request)
3 Height of spindle centers: 125mm
4 Graduated cylinder: 45CC or 150CC
5 Volume of fuel tank: 60L
6 DC.Supply: 12/24V
7 Feeding fuel pressure: Low:0-0.4Mpa High:0-4Mpa
8 Range of speed: +/-4000RPM
9 Fuel test accuracy Accessories: 5u

Hot Questions:

1.Does your company a distributor or a manufacturer?

Our company is specialized in the producing of the diesel fuel injection test bench by ourselves for more than 10 years, we have our factory and so can provide you the best price.

2.Is the operation easy?How about the instructions?

Dear customer,we design the machine for the beautiful style and easy operation. We provide the operation instructions with the machine even in your language.And also can provide the operation vedio.

3.Payment method and the delivery time.

We accept bank transfer,Western Union or Paypal. Accept L/C,TT.

The machine will be produced as soon as possible when receive the payment,often within 8 days.

so waiting for your inquiry!!!

Company Profile

Taian Xingzhou Experimental Equipment Co., Ltd.

Located at the foot of World famous Mountain Tai, Tai'an Xingzhou Experimental Equipment Co., Ltd. is one of the main manufacturers of testing equipment and calibration equipment.
Our products include EM and HT Series Diesel Fuel Injection Pump Test Bench, Common Rail Injector Test Bench, EDC Electronic Tester, Diesel Electronic Monomer Pump Test Bench, Nozzle Tester, and Tools for Pumps. They can meet the demands of different clients. Our company was established in 2002, developing fast and integrating the research, design and innovation. We have tremendous technical strength, advanced crafts, completed checking equipment, and perfect quality system, and we have established a good working relationship with some universities from at home and abroad.
Our products are sold all over China and exported to America, Europe, Russia, Brazil Argentina, Singapore, Mongolia, Austria and the Middle Asia.
