Help CenterPCM-AH Fuel Injection Pump Test Bench
Related Products
-
GPS916 Fuel Injection Pump Test StandNegotiableMOQ: 1 Set -
PCM-E Fuel Injection Pump Test-bedUS$ 3,500 - 4,000MOQ: 1 Set
-
PCM-E Fuel Injection Pump Test StandUS$ 3,500 - 4,000MOQ: 1 Set
-
12PSB-C Fuel Injection Pump Test StandUS$ 3,400 - 4,510MOQ: 1 Set
-
PCM-AH Fuel Injection Pump Test-bedNegotiableMOQ: 1 Set
Specifications
PCM-AH fuel injection pump test benchSPECIFICATIONS
1.frequency control of motor speed
2.easy to operate
PCM-AH fuel injection pump test bench
FUNCTIONS
1 Testing 12-cylinder fuel injection pump.
2 Measuring each cylinder delivery at any speed.
3 Checking each cylinder injection timing with static.
4 Checking the sealing injection pump body.
5 Checking the mechanical governor.
6 Checking the pneumatic governor.
7 Checking the vacuum capacity of governor.
8 Checking the pressure compensators(LDA).
9 Measuring the internal pressure of distributor pump body.
10 Testing the electromagnetic valve of distributor pump.
11 Checking transfer pump.
12 Measuring the reflux delivery of distributor pump body.
PARAMETERS
Output power: 7.5KW,11KW,15KW
2.Electronical supply: 3-Phase 380V/50HZ (or on request)
3.Interaxe height: 125mm
4.Graduates:45CC,150CC
5.Volume of fuel tank: 60L
6.DC.Supply:12/24v
7.Feeding fuel pressure: Low(0-0.4Mpa) High(0-4Mpa)
8.Range of speed:+/-4000RPM
9.Range of rack:0-25mm
10.Air pressure:-50 +300Kpa
11.Control fuel temerature:40+/-2°C
